3. Network Ports Configuration

It sets the HTTP Port number to use when the SSC17WEB Server communicates with a Client PC.

The present SSC17WEB Server uses HTTP Port (80).

- HTTP Port

1)This is the port the Client PC uses to connect to the web page of the SSC17WEB Server. Depending on the environment of the network, its value can be varied.

2)The fault values is 80 and it can be assigned up to 65535 maximum.

*If you change the value of the HTTP Port, you should type in the new one with the address of the SSC17WEB Server in the address window of the web browser.

(Ex. If the IP address of the SSC17WEB Server is 192.168.1.100 and the HTTP Port :

8080, http://192.168.1.100:8080.)

3) Click Apply button to apply the present setting.

CAUTION

Set the port be used when connecting to SSC17WEB in internet Explorer.

The port setting is used for various network configuration when avoiding the network where firewall constitutes or a particular port Etc.

Eng-67
