Heat & Glo LifeStyle 36DV owner manual Alcove Applications

Page 11

R

M

N

P

Q

(See Note 2)

V

T

VS Electrical S

Service

D*

V

V

V

= VENT TERMINAL

X = AIR SUPPLY INLET

= AREA WHERE TERMINAL IS NOT PERMITTED

A

=

12 inches

clearances above grade, veranda,

L**

=

.7 ft

clearance above paved





(See Note 1)

porch, deck or balcony









(See Note 1)



sidewalk or a paved driveway

B

=

12 inches

clearances to window or door

















located on public property

M*** =

18 inches

clearance under veranda, porch,







that may be opened, or to perma-







nently closed window. (Glass)

















deck, balcony or overhang

D*

=

22 inches

vertical clearance to unventilated









42 inches

vinyl













soffit or to ventilated soffit located

S

=



6 inches

clearance from sides of electri-







above the terminal











(See Note 5)



cal service











*42 inches

for vinyl clad soffits and below

T

=

12 inches

clearance above electrical







electrical service









(See Note 5)



service







F

=

9 inches

clearance to outside corner































Alcove Applications











G

=

6 inches

clearance to inside corner



















N



=

6 inches

non-vinyl sidewalls



H

=

3 ft. (Canada)

not to be installed above a gas



















12 inches

vinyl sidewalls









meter/regulator assembly within 3























P



=

8 ft.



















feet (90 cm) horizontally from the

























center-line of the regulator















































QMIN



RMAX





I

=

3 ft

clearance to gas service regulator





























1 cap



3 feet



2 x Q ACTUAL











vent outlet

















J

=

9 inches (U.S.A.)











2 caps



6 feet



1 x Q ACTUAL









12 inches (Canada) clearance to non-mechanical







































3 caps



9 feet



2/3 x Q ACTUAL











air supply inlet to building or the























combustion air inlet to any other









4 caps



12 feet



1/2 x Q ACTUAL











appliance



























K

=

3 ft. (U.S.A.)







QMIN

= # termination caps x 3

RMAX = (2 / # termination caps) x QACTUAL





















6 ft. (Canada)

clearance to a mechanical (pow-































































ered) air supply inlet





























































**a vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings.

***only permitted if veranda, porch, deck or balcony is fully open on a minimum of 2 sides beneath the floor, or meets Note 2.

Note 1: On private property where termination is less than 7 feet above a sidewalk, driveway, deck, porch, veranda or balcony, use of a listed cap shield is suggested. (See vents components page)

Note 2: Termination in an alcove space (spaces open only on one side and with an overhang) are permitted with the dimensions specified for

vinyl or non-vinyl siding and soffits. 1. There must be 3 feet minimum between termination caps. 2. All mechanical air intakes within 10 feet of a termination cap must be a minimum of 3 feet below the termination cap. 3. All gravity air intakes within 3 feet of a termination cap must be a minimum of 1 foot below the termination cap.

Figure 4.4 Minimum Clearances for Termination

Note 3: Local codes or regulations may require different clearances.

Note 4: Termination caps may be hot. Consider their proximity to doors or other traffic areas.

Note 5: Location of the vent termination must not interfere with access to the electrical service.

WARNING: In the U.S: Vent system termination is NOT permitted in screened porches. You must follow side wall, overhang and ground clearances as stated in the instructions.

In Canada: Vent system termination is NOT permitted in screened porches. Vent system termination is permitted in porch areas with two or more sides open. You must follow all side walls, overhang and ground clearances as stated in the instructions.

Heat & Glo assumes no responsibility for the improper performance of the appliance when the venting system does not meet these requirements.

CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS SUGGESTED THAT A VINYL PROTECTOR KIT BE INSTALLED.

Heat & Glo • Escape-36DV2012-900 • Rev. AA • 04-08

11
