MPF50S SERIES PORTABLE FILTRATION SYSTEMS

CHAPTER 3: FILTER PREPARATION

3.1 Assembling The Filter System

On initial installation and before each use, remove all loose parts from the filter, wash all accessories in hot, soapy water and dry thoroughly. DO NOT WASH INTERIOR OF FILTER PAN WITH DETERGENT OR WATER! Wipe debris and residue from the filter pan with a damp cloth or paper towel, then with a dry cloth or paper towel.

WARNING!

Water, detergent or boil-out solution MUST NOT be allowed into the filter pan or filter system. Irreversible pump damage will result if water is allowed into the system, and the warranty will be voided.

MPF50S Series portable filtration systems use a filter support grid, one sheet of filter paper and a hold-down ring to secure the filter paper in place.

See illustration for proper assembly.

1.Filter Pan Cover

2.Hold-Down Ring

3.Filter Paper (one sheet)

4.Screen/Support Grid

5.Filter Pan

3-1
