Fisher & Paykel RX594, RX693, RX616 Care and cleaning, Refrigerator cleaning chart

Page 35

Care and cleaning

Refrigerator cleaning chart

Important!

When cleaning your refrigerator, please pay attention to the chart below. Improper cleaning can result in damage to your refrigerator. Do not place buckets, shelves, or accessories in the dishwasher.

33

Part

Do

Do not use

Cabinet Exterior

Use warm, soapy water and a soft,

Abrasive or harsh cleaners.

Stainless steel doors and all

clean cloth or sponge.

Ammonia.

other exterior surfaces.

Rinse surfaces with clean, warm

Chlorine bleach.

Important: Damage

water and dry immediately to avoid

Concentrated detergents

to exterior finish due

water spots.

or solvents.

to improper­ use of



Metal or plastic-textured

cleaning products or non-



scouring pads.

recommended ­products



Vinegar-based products.

is not covered under this





Citrus-based cleaners.

product’s ­warranty.







Cabinet Interior

Use 4 tablespoons of baking soda

Abrasive or harsh cleaners.



dissolved in 1 L of warm, soapy

Ammonia.



water. To remove odours, put a few

Chlorine bleach.



drops of vanilla essence or vinegar



Concentrated detergents



in water solution.



or solvents.



Rinse surfaces with clean, warm



Metal or plastic-textured



water and dry immediately to avoid



scouring pads.



water spots.











Door Gaskets

Use warm, soapy water and a soft, clean cloth or sponge.

Abrasive or harsh cleaners.

Metal or plastic-textured scouring pads.

Condenser Coil

Use a vacuum cleaner hose nozzle.

Anything other than a

Remove base grille to access.



vacuum cleaner.







Condenser Fan Outlet Grille

Use a vacuum cleaner hose nozzle



See back of refrigerator.

with brush attachment.



Accessories

Follow removal and installation

A dishwasher.

Shelves, buckets, drawers,

instructions from appropriate



drip tray, etc.

feature section.





Allow items to adjust to room





temperature if required.





Dilute mild detergent and use a soft,





clean cloth or sponge for cleaning.





Use a plastic bristle brush to get into





crevices. Rinse surfaces with clean,





warm water.





Dry glass and plastic items





immediately to avoid spots.



Page 34 Page 36
Image 35
