User Preferences menu (RX693 / RX594 models)

User Preferences menu

The User Preferences menu allows you to further customise your refrigerator, altering the settings to suit you.

To access the User Preferences menu, hold down the compartment button for four seconds. When in the User Preferences menu, a short title for the feature will appear in the left/freezer temperature display and the feature status will appear in the right/refrigerator temperature display. For example, dEG will appear in the freezer screen and ˚C or ˚F will appear in the refrigerator screen.

Use the COMPARTMENT button to scroll through the features.

When the desired feature is displayed, use the and buttons to change the status or setting of the feature.

To exit the menu, hold down the compartment button for another four seconds.

The following features can be accessed through the User Preferences menu.

Celsius / Fahrenheit (dEG)

The display can show the temperature in degrees Celsius (˚C) or degrees Fahrenheit (˚F). The temperature will change in 1˚ increments for both F or C settings.

Sabbath mode (SAb)

When Sabbath mode is on, the display screen, all control and exterior lights and the door alarms are disabled until the feature is turned off. This feature does not disable the interior lights. Sabbath mode will automatically deactivate after 80 hours, if not turned off earlier. When Sabbath mode is on, the display will be inactive apart from a small red candle on the display.

Temperature Alarm (see page 15) and the door alarm function will not operate if refrigerator is in Sabbath mode.

Sound (Snd)

Turning the sound off, silences the button presses on the display and all audible alarms. icon will appear on the display when the sound is off. Turning sound off turns the door alarm function off. Temperature Alarm will remain on when the sound is turned off, but the alarm will not sound. Only the visual feedback from the display will be given (see page 15).

Door Alarm (dor)

When the door alarm function is on, an alarm will sound if either door on the refrigerator is left open for longer than five minutes. This is to remind you to close the open door(s).

The door alarm will turn off when either Sabbath mode is turned on or when sound is turned off.

Page 15 Page 17
Image 16
