34

Care and cleaning

Removing odours from refrigerator

WARNING!

Electric Shock Hazard

Disconnect power to refrigerator before cleaning. After cleaning, reconnect power.

Failure to do so can result in death or injury to persons.

1Remove all food from the refrigerator and turn the refrigerator off.

2Disconnect power to the refrigerator.

3Clean the walls, floor, ceiling of cabinet interior, drawers, shelves and gaskets according to the instructions (see page 33).

4Dilute mild detergent and brush solution into crevices using a plastic bristle brush. Leave for five minutes. Rinse surfaces with warm water. Dry surfaces with a soft, clean cloth.

5Wash and dry all bottles, containers and jars. Discard spoiled or expired items.

6Wrap or store odour-causing foods, eg onions, fish, meat or leftovers, in tightly sealed containers to prevent recurring odours.

7Reconnect power to refrigerator and return food to refrigerator.

8After 24 hours, check if odour has been eliminated.

9If the odour is still present, liquid may have spilled down into the evaporator tray. In this instance a service call may be required (see page 46).

Energy saving tips

There are many simple things that can be done to save energy.

During installation

Locate refrigerator in coolest part of room. Avoid areas of direct sunlight, or near heating ducts, registers, or other heat producing appliances. If this is not possible, isolate exterior by using a section of cabinet or an added layer of insulation.

Be sure the doors are closing securely by levelling refrigerator.

During use

Avoid overcrowding shelves, as this reduces airflow.

Do not use any material (such aluminium foil, wax paper, or paper towelling) as a shelf liner, this reduces air flow.

Avoid adding too much warm food all at once, this reduces cooling power. Your refrigerator is most efficient when two thirds full.

Organise items in your refrigerator to reduce the time that the door is open.

Maintenance

Clean door gaskets every three months (see page 33).

Clean condenser coils (see page 33).

Page 35 Page 37
Image 36
