Samsung RS2533SW Temperature Control, Cold Water, Push the ice dispenser lever with a cup

Page 7

TEMPERATURE CONTROL

Freezer

•The freezer temperature can be set between 8°F and -14°F.

•Press the Freezer Temp. button repeatedly until the desired set temperature is shown in the temperature display.

•The temperature display changes in sequence between 8°F and -14°F. When the display reaches 8°F, it returns to -14°F.

•After five seconds, the display reverts to the actual freezer temperature. The unit will then work to adjust to the new desired temperature.

Refrigerator

•The refrigerator temperature can be set between 46°F and 34°F.

•Press the Fridge Temp. button repeatedly until the desired temperature is shown in the temperature dis- play.

•The temperature display changes in sequence and reverts in the same way as the freezer.

•When ice cream is stored above 4°F in freezer, it may melt.



• The temperature of the freezer or the refrigerator rises from frequent openings, when sweeping

WARNING

and from warm food. This may cause the digital display to blink . The digital display will stop

blinking when the freezer and refrigerator return to the normal temperature.



ICE and COLD WATER DISPENSER

Ice Dispenser

The ice maker produces 10 cubes at once and about

120 cubes a day automatically. This quantity may be influ- enced by factors such as the freezer temperature, Power Freeze function and the number of door openings. When your refrigerator is plugged in, the Cubed ice mode is automatically selected .

Press the Ice Type button to select the type of ice:

• Cubed ice

• Crushed ice

• No ice

No ice

Water Dispenser

The capacity of the water tank is approximely 0.3 gal.

Cold Water

•Push the water dispenser lever with a cup.

•If you have just installed the refrigerator, throw away the first six glassfuls of water to flush out impurities in the water supply system.

Push

If the Ice remains in the Ice bucket, the



If you have a long vacation or business trip

NOTE cubed ice is obtained.





and won’t use the water or ice dispensers,

Push the ice dispenser lever with a cup.

CAUTION

close the water valve. Otherwise, leakage

• Place a cup in line with the dispenser lever the

of water may occur.





dispenser to prevent the ice from jumping out.





Push





Never put fingers or any other objects in the

NOTE dispenser opening. It may cause injury.

7
