REATTACHING THE REFRIGERATOR DOORS

Reattaching the Water Supply Line

1)While pressing the front face of coupler (➁), insert the water line (➀) in the coupler.

2)Tighten the screw on the clamp ( a ).

a

Reattaching the Front Leg Cover

Put on the front leg cover by turning the three screws clockwise, as shown in the figure.

FRONT LEG COVER

SCREW

23
