Tappan 316000182 important safety instructions To Remove and Replace Oven Door

Page 16

General Cleaning

(continued)

The door is heavy. For safe, temporary storage, lay the door flat with the inside of the door facing down.

To Remove and Replace Oven Door

To Remove Oven Door:

1.Open the door.

2.Remove screws located on the inside of the oven door near the hinges A (one on each side.)

3.Close the door to the quarter-open position. Grasp the door firmly on both sides and lift up and off the hinges.

4.To clean oven door, follow the instructions provided in the cleaning chart under General Cleaning

To Replace Oven Door:

1.

Be sure the hinge arms are in the quarter-open position. Be careful if pulling



the hinges open by hand. The hinges may snap back against the oven frame



and could pinch fingers.

2.

Hold the door at the sides near the top. Insert the hinge arms into slots at



the bottom of the door.

3.

Hinge arms must go into the range slots evenly. The hinge arms should be



inserted into the bottom corners of the door as far as they can go.

4.

If the door is not in line with the oven frame, remove it and repeat the above



steps.

To Remove and Replace Gas Warmer Drawer (if equipped)

To Remove Warmer Drawer:

1.

Turn power off before removing the warmer drawer.

2.

Open the drawer to the fully opened position.

3.

Locate glide lever on each side of drawer, pull up on the left glide lever and



push down on the right glide lever (see figure 1).

5.

Pull the drawer away from the range.

To Replace Warmer Drawer:

1.

Pull the bearing glides to the front of the chassis glide (see figure 2).

2.

Align the glide on each side of the drawer with the glide slots on the range.

3.

Push the drawer back into the range.

Figure 1

Electrical Shock Hazard can occur and result in

serious injury or death. Disconnect appliance from electric





power before cleaning and servicing the warmer drawer.

Figure 2



16
