Section 3: Operating Procedures

Operating Check List

It is absolutely essential that no one operates the Rotary Cutter without first having read, fully understood and become totally familiar with the Operator’s Manual. Make sure the operator has paid particular attention to:

•Important Safety Information, pages 1 to 7

•Section 1: Assembly and Set-Up,page 10

•Section 2: Adjustments, page 22

•Section 3: Operating Procedures, page 24

•Section 4: Maintenance & Lubrication, page 28

In addition to design and configuration of equipment, hazard control and accident prevention are dependent upon the awareness, concern, prudence and proper training involved in the operation, transport, maintenance and storage of equipment. Before beginning to cut, the following inspection should be performed.

IMPORTANT: Stop PTO immediately if vibration continues after a few revolutions during start-up and anytime it occurs thereafter. Wait for PTO to come to a complete stop before dismounting from tractor to check for probable causes. Make necessary repairs and adjustments before continuing on.

7.Start tractor, set throttle to idle or slightly above idle and slowly engage the PTO. Initial start-up vibration is normal and should stop after a few revolutions.

Stop PTO rotation immediately if vibration continues.

IMPORTANT: Do not exceed rated PTO speed of the cutter. Excessive engine speed will cause damage to the power train components.

8.Once the cutter is running smoothly, increase tractor PTO speed to 540 RPM. Stop PTO rotation immediately if vibration occurs.

Operating Checklist

			Check	Reference
			“Important Safety Information” in	Page 1
			“Important Safety Information” in	Page 1
			this Manual.
			this Manual.

			Check oil level in gearboxes.	Section 3
			Check oil level in gearboxes.	Section 3
				Page 32
				Page 32

			Check that all plugs in gearbox have	Section 3
			Check that all plugs in gearbox have	Section 3
			been replaced properly.	Page 32
			been replaced properly.	Page 32

			Be sure nuts and bolts are tight.	Section 7

			Be certain all guards and shields	Section 1
			Be certain all guards and shields	Section 1
			are in place.	Page 15
			are in place.	Page 15

			Lubricate the cutter as needed.	Section 4
			Lubricate the cutter as needed.	Section 4
			Refer to “Maintenance and	Page 28
			Refer to “Maintenance and	Page 28
			Lubrication”.

Make the following inspections after hooking-up to the cutter. See hook-up instructions beginning on page 17. Make certain the PTO is disengaged and completely stopped before continuing.

1.Inspect tractor safety equipment to make sure it is in good working condition.

2.Carefully raise and lower implement to ensure that the drawbar, tires, and other equipment on the tractor do not contact the cutter frame or PTO driveline.

3.Check all hoses and wires to be sure that they will not contact PTO driveline. Check PTO guards to make certain they are in good condition and in place.

4.Inspect Hydraulic hoses for wear, damage and hydraulic leaks. See “Avoid High Pressure Fluids Hazard” on page 3. Replace damaged and worn hoses with genuine Land Pride parts.

5.With the PTO disengaged and completely stopped, check cutting blades for sharpness.

6.(Lift-Type Cutter) Adjust tractor lower 3-point arms such that the PTO driveline is approximately level.

Transporting the Cutter

!CAUTION!

When traveling on public roads at night or during the day, use accessory lights and devices for adequate warning to operators of other vehicles. Comply with all federal, state and local laws.

IMPORTANT: Always disengage the tractor’s PTO before raising the cutter to transport position.

1.Make sure driveline does not contact tractor or cutter when raising cutter to the transport position.

2.Reduce tractor ground speed when turning and leave enough clearance so cutter does not contact obstacles such as buildings, trees or fences.

3.Limit transport speed to 20 mph. Transport only with a farm tractor of sufficient size and horse power.

4.When traveling on roadways, transport in such a way that faster moving vehicles may pass you safely.

5.Shift tractor to a lower gear when traveling over rough or hilly terrain.

Un-hooking the Cutter

The following steps should be done when un-hooking the cutter from the tractor.

1.Park on a level solid surface.

2.Shut tractor engine off and engage parking brake.

•Lift-Type: Lower deck to level ground or onto blocks supporting deck just above ground level.

•Pull-Type: See Pull-Type Tractor Un-Hook on page 20.

3.Unhitch from tractor.

4.See “Storage Instructions” on page 31 if cutter is not going to be used for a long time.

24 RCR2596, RCR2510 and RCRM2510 Rotary Cutters 312-753M

5/09/08
