Jacuzzi J-DREAM II owner manual Attach Door Frame to Angle Brackets and Base Frame

Page 19

J-Dream II Owner's Manual

Attach Door Frame to Angle Brackets and Base Frame

Before proceeding, make sure the seat walls are closed and fastened. See detail B on page 15. Align door frame over tabs on base frame and pan lip. Pan lip is to fit into corner posts of door frame. Align holes along sides of door frame with angle brackets and mark this position of the angle brackets. Remove door frame and angle bracket screws. Apply the silicone caulk and reinstall the angle brackets at the marked position. Insert screws and tighten. Reposition the door frame and install screws through angle brackets into door frame post. Then install bolts (2) through frame tabs into door frame. Do not over tighten. Do not silicone caulk angle brackets to door frame as they allow service access to equipment.

B

Enclosure

Post

Panel #1

E

Screw (3)

Panel #1

Angle Bracket

A

Screw (3)

A E





Enclosure



Panel #4

Post







Angle Bracket







B

C

Enclosure

Washer (2)

Post

I

Panel #4

Base Frame Bolt (2) H

C

17

Image 19
