Operation

Chipping & Shredding Recommendations

















Operation

Type of Waste

Size Limitations

Notes



Permitted















Shredding

Dry or moist organic material

Branches and twigs up to 1/2”

Alternately chip or shred moist green waste



including leaves, plants,

diameter and 18” long.

with dry waste to avoid plugging of the



flowers, fruits, or vegetables.



discharge chute.







Process at a feeding rate that allows the







rotor to keep up and maintain a high rate







of speed.









Chipping

Long, thicker tree limbs or

Tree limbs and branches,

Bulky tree limbs should be pruned close



small bunches of smaller

or bundles of small sticks

to the main stem. Always use a shorter



sticks grouped together for

grouped for easier handling.

piece of wood to push end pieces into the



ease of handling.

Maximum diameter of

chipper cone. Never place hands in the





approximately 3” (7,6 cm).

chipper cone.







Never chip very hard or dry materials such







as kiln dried dimensional lumber (2x4’s etc.)







or other building materials.







Never use the chipper to process pressure-







treated wood products.









Vacuum

Light, loose, dry waste such

Small materials that will not

The vacuum is engineered for small, loose

Attachment

as leaves, grass clippings, or

obstruct the vacuum hose.

waste and for cleaning around decorative



sawdust.



landscaping and flower beds. Twigs, wet







leaves, and other bulky materials will







clog the hose or obstruct the shredding







chamber.











Storage

Before you store your unit for the off-season, read the Maintenance and Storage instructions in the Safety Rules section, then perform the following steps:

Perform engine maintenance and storage measures listed in the engine owner’s manual. This includes draining the fuel system, or adding stabilizer to the fuel (do not store a fueled unit in an enclosed structure - see warning).

Before starting the unit after it has been stored:

Check all fluid levels. Check all maintenance items.

Perform all recommended checks and procedures found in the engine owner’s manual.

Allow the engine to warm up for several minutes before use.
