BATTERY INSTALLATION

1.Slide the cover off the back of the remote as shown in Figure 9d, pressing in and sliding the cover down to release.

2.Install the included 12 volt alka- line battery (Type 23A, MN-21 or equivalent) inside the remote, matching polarity on the Battery as indicated by the + and - sym- bols in the Battery Compartment. See Figure 9d. Replace the cover.

DIP SWITCH SETTING

Note: You will only have to change the DIP switch settings in the remote if you are using more than one re- mote controlled fan in the same area and want to control them separately.

1.At the circuit breaker or fuse box, turn the power off for the fan you want to change.

Figure 9d

2.Slide the cover off the back of the remote and remove the bat- tery. The battery must be re- movedwhenchangingdipswitch settings. Refer to BATTERY IN- STALLATION and Figure 9d.

3.Change the DIP switch settings, assuring that they are different from the previously installed fan. Refer to Figure 9e.

4.Replace the battery and cover.

5.At the circuit breaker or fuse box, turnthepowerbackonforthefan whosesettings youarechanging.

6.Within 20 seconds of restoring power, push the Hi, Med, and Lo buttons (in that order). Refer to Figure 9f.

Note: You may want to label your controls to assure you do not mix themup.

DIP Switch

DIP Switch

Set to

Set to

01110

01001

Figure 9e

41462-01 10/14/2005

19
