September 2004
AC508A
AC509A
(AC508A) 2 In 4 Out
(AC509A) 2 In 8 Out
CUSTOMER | Order |
SUPPORT | |
INFORMATION | FREE technical support, 24 hours a day, 7 days a week: Call |
| fax |
| Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA |
| Web site: www.blackbox.com • |
Introduction
Through the video matrix, you can use 2 PCs to display the diverse images on 2,4,8 monitors; meanwhile, optional means for controlling monitor’s image either come from PC “A” or PC “B” or just switching off. Video matrix is ideal for:
| Presentation |
| Stock quotes |
| Timetables |
| Educational facilities |
Features
Intelligent functionality.
With 250 MHz pixel frequency.
Extends the video signal up to 65 meter (213 feet).
Supports the DDC, DDC2, DDC2B. (For video out port 1 and 2)
Can be cascaded.
The output is compatible with standard VGA card.
Free select from PC ○A or PC ○B or switch off by means of the front panel switch.
Specifications
Function | AC508A |
| AC509A | |||
|
|
|
|
| ||
Video Input Connector | 2 |
| 2 | |||
| ||||||
|
|
| ||||
Video Output Connector | 4 |
| 8 | |||
| ||||||
|
|
| ||||
Select Switch | 4 |
| 8 | |||
Linked |
| A (Green) | 4 |
| 8 | |
LEDs |
| B (Red) | 4 |
| 8 | |
Max. Resolution | 1920 x 1440 | 60 Hz | ||||
Pixel Frequency | 250 MHz | |||||
Cable Distance | 65m (213 feet) Max. | |||||
(Device to Monitor) | ||||||
|
|
| ||||
Signal Type | VGA, SVGA, XGA, Multisync | |||||
Power Adapter (Min.) | AC 7.5V 800mA | |||||
| Housing | Metal |
| |||
| Weight | 455 g |
| 680 g | ||
Dimensions (LxWxH) mm | 130x75x42 |
| 200x75x42 | |||
Technical Specifications
Input/Output Signal
Pin # | Signal |
| Pin # | Signal |
1 | Red video |
| 9 | NC |
2 | Green video |
| 10 | Ground |
3 | Blue video |
| 11 | ID0 ﹡ |
|
|
|
|
|
4 | ID2 ﹡ | 12 | ID1 ﹡ | |
|
|
|
|
|
5 | Ground | 13 | Horizontal sync | |
6 | Analog ground |
| 14 | Vertical sync |
7 | Analog ground |
| 15 | ID3 ﹡ |
8 | Analog ground |
|
|
|
﹡For video out port 1 and 2.
FRONT VIEW
1.Select
2.○A ,○B Linked
REAR VIEW
1.Input Power Jack
2.○A ,○B “Video In” Port
3.“Video Out” Port
*There are 4 ports for AC508A and 8 ports for AC509A.
