E

Using a Memory Card

4.Select the desired setting.

•Your currently recording image is combined with the pre-recorded still image.

5.Select MIX LEVEL.

6.Adjust the mix level.

•Turning the selector dial upwards adjusts to the right and turning downwards adjusts to the left.

7.Close the menu.

•CARD MIX flashes in the display.

On/Off

8.Press the card MIX button.

•CARD MIX stops flashing.

•Your currently recording image is combined with the pre-recorded still image.

•Each time you press the card MIX button, your selection is activated (display lights continuously) or deactivated (display flashes).

For a moving image

1.Press the start/stop button to start and stop recording.

• The combined images are recorded onto the cassette.

For a still image

1.Press the PHOTO button halfway down and hold it.

•F flashes white in the display as the camcorder adjusts the focus and it is displayed continuously as a green mark when the camcorder is ready to take the image.

2.Press the PHOTO button fully down to record the image to the cassette.

•F disappears from the display.

•The combined images are recorded onto the cassette for approximately 6 seconds (8 seconds in the SP or LP recording mode).

Notes:

•If you change the position of the POWER switch or move the program selector from Q to [ Easy Recording mode, select your still image for Card Mix again.

•When setting Card Mix, you must carry out steps 1 to 4.

112

Image 112
