Office Rack Mount UPS
OR1000LCDRM1U/OR1500LCDRM1U
User’s Manual
IMPORTANT SAFETY INSTRUCTIONS
(SAVE THESE INSTRUCTIONS)
This manual contains important instructions that should be followed during installation and maintenance of the UPS and batteries. Please read and follow all instructions carefully during installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install, or operate.
CAUTION! The UPS must be connected to a grounded AC power outlet with fuse or circuit breaker protection. DO NOT plug the UPS into an outlet that is not grounded. If you need to
CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! CyberPower Systems does not sell products for life support or medical applications. DO NOT use in any circumstance that would affect the operation or safety of any life support equipment, with any medical applications, or patient care.
CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected.
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area, free of conductive contaminants. (Please see specifications for acceptable temperature and humidity range).
CAUTION! To reduce the risk of electric shock, do not remove the cover, except to service the battery. There are no user serviceable parts inside, except for the battery.
CAUTION! To avoid electrical shock, turn off the unit and unplug it from the AC power source before servicing the battery or installing a computer component.
CAUTION! DO NOT USE WITH OR NEAR AQUARIUMS! To reduce the risk of fire, do not use with or near aquariums. Condensation from the aquarium can come in contact with metal electrical contacts and cause the machine to short out.
CAUTION! DO NOT USE WITH LASER PRINTERS! The power demands of laser printers are too large for a UPS.
INSTALLING YOUR UPS SYSTEM
INSPECTION
The box should contain the following:
(1)PowerPanel® Business Edition software (CD); (1) RS232 cable
(1)user manual; (1) Warranty registration card; (1) UPS unit; (2) Rack mount rails;
(2) Rack mount brackets.
OVERVIEW |
|
|
| |
Automatic Voltage Regulators | ||||
The OR1000LCDRM1U/OR1500LCDRM1U provides automatic voltage regulation for inconsistent utility | ||||
increase low or decrease high voltage to a computer | ||||
power. The OR1000LCDRM1U/OR1500LCDRM1U features 1030 Joules of surge protection, and | safe 110/120 volts. The AVR automatically provides | |||
|
| |||
provides battery backup during power outages. The OR1000LCDRM1U/OR1500LCDRM1U ensures | battery | |||
volts or exceeds 140 volts. |
| |||
consistent power to your computer system and its included software will automatically save your open |
|
| ||
files and shutdown your computer system during a utility power loss. | AVR |
| ||
AUTOMATIC VOLTAGE REGULATOR | INCONSISTENT | CONSISTENT | ||
|
| UTILITY POWER | SAFE POWER | |
The OR1000LCDRM1U/OR1500LCDRM1U stabilizes inconsistent utility power. The incoming utility
power may be damaging to important data files, but with Automatic Voltage Regulation, the computer will not experience damaging voltage levels. An Automatic Voltage Regulator automatically increases low or decreases high voltage to a consistent, computer safe 110V/120V. The unit’s powerful sealed
HOW TO DETERMINE THE POWER REQUIREMENTS OF YOUR EQUIPMENT
1.Make sure that the total
2.Ensure that the equipment plugged into the four battery
3.If the power requirements of your equipment are listed in units other than
Watts (W) x 1.67 = VA or Amps (A) x 120 = VA
Add the totals up for all pieces of equipment and multiply this total by 0.6 to calculate the approximate requirements.
There are many factors that can affect the amount of power that your computer system will require. The suggested total load that you will be placing on the
BASIC OPERATION
DESCRIPTION
1. LCD module display | 1 | 2 | 3 | 4 |
|
|
|
|
|
|
|
|
|
|
|
| |
LCD shows all the UPS information with icons and |
|
|
|
|
|
|
|
|
messages. |
|
|
|
|
|
|
|
|
2. Power On Indicator |
|
|
|
|
|
|
|
|
This LED is illuminated when the utility condition is |
|
|
|
|
|
|
|
|
normal and the UPS outlets are providing power, |
|
|
|
|
|
|
| AC INPUT |
free of surges and spikes. |
|
|
| UNINTERRUPTIBLE | IN | OUT |
|
|
3. Power Switch |
|
|
| POWER SUPPLY |
| SERIAL | Push To | FAULT |
|
|
| E187679 |
| ||||
|
|
|
| 6G48 |
|
| RESET | WIRING |
Master on/off switch for equipment connected to the | 5 |
| 6 | 13 | 7 8 | 9 | 10 11 12 | |
battery power supplied outlets. |
| |||||||
4. LCD function selected switch
The switch can be used to select the LCD display contents Including input/output voltage and estimated run time, etc.
5. Battery, Surge and AVR Outlets
Provides four battery power, surge protected and AVR outlets for connected equipment and ensures temporary uninterrupted operation of your equipment during a power failure.
6. Surge Outlets
Provides two surge protected outlets for connected equipment.
7. Communication Protection Ports RJ11/RJ45
Communication protection ports will protect any standard modem, fax, telephone line, or network cable.
8. USB Port to PC
This port allows connection and communication from the USB port on the computer to the UPS unit. The UPS communicates its status to the PowerPanel® Business Edition software. This interface is also compatible with the UPS application provided by Windows Vista and Mac OS X.
9. Dry contact
This port produces information for equipment that can read dry contact signals.
10. Circuit Breaker
Located on the side of the UPS, the circuit breaker serves to provide overload and fault protection. Under normal operating conditions, the circuit breaker is depressed.
11. Electrical Wiring Fault Indicator
This LED indicator will illuminate to warn the user that a wiring problem exists, such as bad ground, missed ground or reversed wiring. If this is illuminated, disconnect all electrical equipment from the outlet and have an electrician check to ensure the outlet is properly wired.
12. AC Input
Connect the AC Power cord to a properly wired and grounded outlet.
13. Expansion Port
Allow users to add the optional SNMP card.
Hardware Installation Guide
1.Your new UPS may be used immediately upon receipt. However, recharging the battery for at least four hours is recommended to ensure that the battery's maximum charge capacity is achieved. Charge loss may occur during shipping and storage. To recharge the battery, simply leave the unit plugged into an AC outlet. The unit will charge in both the on and off position.
2.If you will use the software, connect the USB cable to the USB port on the UPS.
3.With the UPS unit off and unplugged, connect the computer, monitor, and any externally powered data storage device (Zip drive, Jazz drive, Tape drive, etc.) into the battery power supplied outlets. DO NOT plug a laser printer, copier, space heater, vacuum, paper shredder or other large electrical device into the UPS. The power demands of these devices will overload and possibly damage the unit.
4.To protect a fax, telephone, modem line or network cable, connect a telephone cable or network cable from the wall jack outlet to the IN jack of the UPS. Then connect a telephone cable or network cable from the OUT jack on the UPS to the modem, computer, telephone, fax machine, or network device.
5.Plug the UPS into a 2 pole, 3 wire grounded receptacle (wall outlet). Make sure the wall branch outlet is protected by a fuse or circuit breaker and does not service equipment with large electrical demands (e.g. air conditioner, refrigerator, copier, etc.). Avoid using extension cords. If used, the extension cord must be grounded and rated for 15 amps.
6.Depress the power switch to turn the unit on. The power on indicator light will illuminate and the unit will "beep" once.
7.If an overload is detected, an audible alarm will sound and the unit will emit one long beep. To correct this, turn the UPS off and unplug at least one piece of equipment from the battery power supplied outlets. Wait 10 seconds. Make sure the circuit breaker is depressed and then turn the UPS on.
8.Your UPS is equipped with an
9.To maintain optimal battery charge, leave the UPS plugged into an AC outlet at all times.
10.To store your UPS for an extended period, cover it and store with the battery fully charged. Recharge the battery every three months to ensure battery life.
BATTERY REPLACEMENT
CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the battery.
Service the battery under the supervision of personnel knowledgeable of batteries and their precautions.
CAUTION! Use only the specified type of battery. See your dealer for replacement batteries. CAUTION! The battery may present the risk of electrical shock. Do not dispose of batteries in a fire, as they may explode. Follow all local ordinances regarding proper disposal of batteries.
CAUTION! Do not open or mutilate the batteries. Released electrolyte is harmful to the skin and eyes and may be toxic.
CAUTION! A battery can present a high risk of short circuit current and electrical shock. Take the following precautions before replacing the battery:
1.Remove all watches, rings or other metal objects.
2.Only use tools with insulated handles.
3.DO NOT lay tools or other metal parts on top of battery or any battery terminals.
4.Wear rubber gloves and boots.
5.Determine if the battery is inadvertently grounded. If inadvertently grounded, remove source of ground. CONTACT WITH A GROUNDED BATTERY CAN RESULT IN
ELECTRICAL SHOCK! The likelihood of such shock will be reduced if such grounds are removed during installation and maintenance (applicable to a UPS and a remote battery supply not having a grounded circuit)
BATTERY REPLACEMENT PROCEDURE:
1 | 2 | 3 |
1. Remove the | 2. Remove the three retaining screws on |
|
the cable protection cover then remove | 3. Disconnect the black and red cable. | |
| the cover. | |
4 | 5 |
|
5. Replace the new battery pack. Assemble the screws, cover, cable and front panel in the reverse sequence of above steps. Recharge the unit for
4.Remove the retaining screw of the cable connectors.
DEFINITIONS FOR ILLUMINATED LCD INDICATORS
LOAD BATT. CAP. INPUT OUTPUT RUN_TIME
| V |
100 | % |
| Min |
Line mode
| Select SW |
|
|
| UPS Status Display |
|
| Capacity Display |
| Digital Value Display |
| |||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
| Press |
|
|
|
|
|
|
|
|
| 100 |
| Load |
| Battery | Input | Output |
| Run |
| % of | % of |
|
|
|
|
|
|
|
|
|
|
|
|
| Cap. |
| Cap. | Voltage | Voltage |
| Time |
| Load | Batt. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Initial |
|
| V |
| X |
|
|
| X |
| V |
| X |
| V |
|
|
|
|
| |
| 1st |
|
| V |
| X |
|
|
| X |
| V |
| X |
|
|
| V |
|
|
| |
| 2nd |
|
| V |
| X |
|
|
| X |
| V |
| X |
|
|
|
|
| V |
| |
| 3rd |
|
| V |
| X |
|
|
| X |
| X |
| V |
|
|
|
|
|
| V | |
| 4th |
|
| V |
| X |
|
|
| X |
| V |
| X | V |
|
|
|
|
|
| |
| 5th(Return) |
|
| V |
| X |
|
|
| X |
| V |
| X |
| V |
|
|
|
|
| |
| Press >3sec |
|
| V |
| X |
|
| V |
| X |
|
|
|
| |||||||
| (Sound Disable) |
|
|
|
|
|
|
|
|
| ||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||
| Press >3sec |
|
| V |
| X |
|
| X |
| X |
|
|
|
| |||||||
| again |
|
|
|
|
|
|
|
|
|
| |||||||||||
| (Sound Enable) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
| (Overload) |
|
| V |
| X |
|
|
| V |
|
|
|
| ||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||
| "V" : Illuminated, | "X" : Not Illuminated, |
|
|
|
|
|
|
|
|
|
|
|
| ||||||||
| Battery mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||
| Select SW |
|
|
| UPS Status Display |
|
| Capacity Display |
| Digital Value Display |
| |||||||||||
| Press |
|
|
|
|
|
|
|
|
| 100 |
| Load |
| Battery | Input | Output |
| Run |
| % of | % of |
|
|
|
|
|
|
|
|
|
|
|
|
| Cap. |
| Cap. | Voltage | Voltage |
| Time |
| Load | Batt. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||||||
| Initial |
|
| X |
| V |
|
|
| X |
| X |
| V |
| V |
|
|
|
|
| |
| 1st |
|
| X |
| V |
|
|
| X |
| X |
| V |
|
|
| V |
|
|
| |
| 2nd |
|
| X |
| V |
|
|
| X |
| V |
| X |
|
|
|
|
| V |
| |
| 3rd |
|
| X |
| V |
|
|
| X |
| X |
| V |
|
|
|
|
|
| V | |
| 4th |
|
| X |
| V |
|
|
| X |
| X |
| V | V |
|
|
|
|
|
| |
| 5th(Return) |
|
| X |
| V |
|
|
| X |
| X |
| V |
| V |
|
|
|
|
| |
| Press >3sec |
|
| X |
| V |
|
| V |
| X |
|
|
|
| |||||||
| (Sound Disable) |
|
|
|
|
|
|
|
|
| ||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||
| Press >3sec |
|
| X |
| V |
|
| X |
| X |
|
|
|
| |||||||
| again |
|
|
|
|
|
|
|
|
|
| |||||||||||
| (Sound Enable) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
| (Overload) |
|
| X |
| V |
|
|
| V |
|
|
|
| ||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||
| "V" : Illuminated, | "X" : Not Illuminated, |
|
|
|
|
|
|
|
|
|
|
|
| ||||||||
|
|
|
|
|
|
|
|
| TROUBLE SHOOTING |
|
|
|
|
|
| |||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||
| Problem |
|
|
|
|
| Possible Cause |
|
| Solution |
|
|
|
| ||||||||
|
|
|
| Circuit breaker has tripped | Turn the UPS off and unplug at least one piece of equipment. | |||||||||||||||||
| outlets stop providing power |
|
|
| Wait 10 seconds, reset the circuit breaker by depressing the | |||||||||||||||||
|
|
|
|
| due to an overload. | |||||||||||||||||
| to equipment. |
|
|
|
|
|
| button, and then turn the UPS on. |
| |||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||||
| The UPS does not provide |
|
|
|
| Battery not fully charged. | Recharge the battery by leaving the UPS plugged in. | |||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||||
| expected runtime. |
|
|
| Battery is slightly worn out. | Contact CyberPower Systems about replacement batteries at | ||||||||||||||||
|
|
|
|
|
|
|
|
| tech@cyberpowersystems.com |
|
| |||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||
|
|
|
|
|
|
|
| The on/off switch is designed | Turn the UPS off. Wait 10 seconds and then turn the UPS on. | |||||||||||||
|
|
|
|
|
|
|
| to prevent damage by rapidly | ||||||||||||||
|
|
|
|
|
|
|
|
| turning it off and on. |
|
|
|
|
|
|
|
| |||||
| The UPS will not turn on. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||||
|
|
|
|
| The battery is worn out. | Contact CyberPower Systems about replacement batteries at | ||||||||||||||||
|
|
|
|
|
|
|
|
|
| tech@cyberpowersystems.com |
|
| ||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
| Mechanical problem. |
| Contact CyberPower Systems at |
|
| |||||||||
|
|
|
|
|
|
|
|
|
| tech@cyberpowersystems.com |
|
| ||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||||
|
|
|
|
|
|
|
|
| The USB cable is not | Connect the USB cable to the UPS unit and an open | ||||||||||||
| PowerPanel® Business |
|
|
|
| connected. |
|
|
| USB port on the back of the computer. |
| |||||||||||
| Edition is inactive. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||
|
|
|
|
| The unit is not providing | Shutdown your computer and turn the UPS off. Wait 10 | ||||||||||||||||
|
|
|
|
|
|
|
|
| ||||||||||||||
|
|
|
|
|
|
|
|
| battery power. |
|
| seconds and turn the UPS on. This should reset the unit. | ||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Additional troubleshooting information can be found at www.cyberpowersystems.com/support.htm
TECHNICAL SPECIFICATIONS
Model | OR1000LCDRM1U |
| OR1500LCDRM1U | |
Capacity | 1000VA(600W) |
| 1500VA(900W) | |
Input Voltage on Utility |
| 90V to 140V | ||
Input Frequency |
| 57 Hz to 63 Hz | ||
Line Conditioning Regulation | AVR Max. boost 12% of input voltage for output regulation while | |||
input voltage is from 16% to 25% under nominal. | ||||
| ||||
| 120Vac +/- 5% | |||
Simulated Sine Wave Form | ||||
Transfer Time |
| 4ms Typical | ||
Overload Protection |
| Yes | ||
Lightning / Surge Protection |
| Yes | ||
Internet Ready | RJ11/RJ45 ( One In/ One Out ) | |||
(DSL/ Phone/ Fax/ Modem Protection) | ||||
|
|
| ||
Operating Temperature | + 32°F to 104°F. (0°C to 40°C) | |||
Maximum Dimensions (cm) | 1U Rack 43.3 x 39.5 x 4.4 |
| 1U Rack 43.3 x 49.0 x 4.4 | |
Weight (kg) | 16.1 |
| 19.4 | |
Typical Battery Recharge Time | 8 hours typical from total discharge | |||
Battery Type |
|
|
| |
Sealed Maintenance | 6V 7.0AH x 4 |
| 6V 9.0AH x 4 | |
Free Lead Acid Battery |
|
|
| |
Indicators | Power On, Wiring Fault, | |||
Audible Alarms | On battery, Low battery, Overload | |||
PowerPanel® Business | Windows 2000 / XP/ Vista | |||
Editon Software | ||||
|
|
| ||
| Yes | |||
| Yes | |||
| Yes | |||
USB |
| Yes | ||
Dry contact |
| Yes | ||
|
|
|
| |
EXPECTED RUNTIME IN MINUTES
| OR1000LCDRM1U | OR1500LCDRM1U | |
iMac G4 | 100 - 110 | 155 | - 170 |
Desktop PC with 17" LCD Monitor | 71 - 80 | 88 - 100 | |
Desktop PC with 19" LCD Monitor | 54 - 62 | 65 | - 75 |
Desktop PC with 21" LCD Monitor | 35 - 42 | 49 | - 58 |
Desktop PC with 17" CRT Monitor | 32 - 38 | 40 | - 48 |
|
|
|
|
CYBERPOWER GREENPOWER UPS TECHNOLOGY
Our new UPS circuit is designed to save energy operating in GreenPower Bypass Mode.
A traditional UPS circuit with AVR provides normal output voltage through the Relay and AVR transformer. The current travels first through the transformer conducting energy and generating heat. This heat creates energy dissipation resulting in a "Power Loss" or consumption of utility power and money.
CyberPower's GreenPower Circuit Design is a solution to this "Power Loss." When the Utility Power is operating normally, our Green Power UPS works in Bypass Mode. Our GreenPower design conducts power only through the Relay and still provides normal output voltage. Bypassing the transformer reduces power consumption thereby conserving energy and saving money. When the utility power is abnormal the UPS will operate under Battery or AVR Mode. Under this condition Green Power UPS and a traditional UPS would operate about the same.
On average utility power operates 88% of the time and the CyberPower GreenPower Technology will work in its money/energy saving Bypass Mode.
Limited Warranty and Connected Equipment Guarantee
In purchasing an OR1000LCDRM1U / OR1500LCDRM1U in the United States or Canada, the original end user receives a Limited Warranty and CyberPower's Power Control Guarantee from Cyber Power Systems (USA), Inc. (for ease of reading, referred to as "CyberPower"). The Limited Warranty and the Power Control Guarantee are intended to be the original
Limited Warranty. The original end user (referred to as the "Initial Customer") receives an express limited warranty (referred to as the "Limited Warranty") for the OR1000LCDRM1U / OR1500LCDRM1U purchased from CyberPower (referred to as the "Product"). The terms of the Limited Warranty are explained below.
Power Control Guarantee. CyberPower provides the Initial Customer with protection in the event that the Product is not free from defects in materials and workmanship, and certain equipment connected to the Product is damaged (the "Power Control Guarantee"). The Power Control Guarantee protects the Initial Customer for damage to equipment plugged into the Product. The terms of the Power Control Guarantee are explained below.
The Limited Warranty and the Power Control Guarantee are subject to the terms set forth below. Additionally, State or Provincial law may adjust the terms of the Limited Warranty or the Power Control Guarantee or the State or Province may impose additional obligations, or additional "implied warranties." To the extent necessary to comply with those laws, the terms of the Limited Warranty and the Power Control Guarantee should be read to adjust to those requirements only to the extent necessary to comply with such local law.
If you are an Initial Customer, you are asked to read the following terms and conditions carefully before using the Product. By using the Product you consent to be bound by and become a party to the Limited Warranty and Power Control Guarantee. If you do not agree to the terms and conditions of the Limited Warranty and Power Control Guarantee, you should return the Product for a full refund prior to using it.
REGISTRATION
CyberPower requests that you complete and return the Warranty Registration Card enclosed with the Product or register the Product at its website (www.cpsww.com) to establish that you are the Initial Customer of the Product, and therefore entitled coverage under the Limited Warranty and the Power Control Guarantee. (Registration is not required for Limited Warranty coverage, but note if you do not complete a registration card you will be required to provide proof of purchase, as described below, to have the benefits of this Limited Warranty.)
LIMITED WARRANTY
CyberPower warrants to you, the Initial Purchaser, that the Product will be free from defects in material and workmanship for three years from the date of original purchase, subject to the terms of this Limited Warranty. This Limited Warranty gives you specific rights, and you may have other rights, which vary from State to State or Province to Province.
Any Implied Warranty of Merchantability or for Fitness for a Particular Purpose, if applicable
to the Product, is limited in duration to the period of ownership by the Initial Customer. This provision shall NOT create any Implied Warranty or Merchantability or of Fitness for a Particular Purpose that would not otherwise apply to the Product.
NOTE: Some States and some Provinces do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
To be covered you must still be the owner of the Product at the time of the failure that results in the claim made under this Limited Warranty.
Exclusive Remedies Under Limited Warranty.
Your exclusive remedy and CyberPower's sole obligations are as follows for the Product:
If (a) the CyberPower Product you purchased and still own is defective in material or workmanship under this Limited Warranty or any applicable warranty imposed by law, and
(b)all Limited Warranty requirements have been met, CyberPower will repair or replace the Product if it proves to be defective in material or workmanship during the Warranty Period.
Making a Limited Warranty Claim.
To make a Limited Warranty claim on a Product, you must do the following:
1.Complete and return the CyberPower Warranty Registration Card, or provide reasonable proof of purchase (for example, a sales receipt) that establishes you as the Initial Customer (the original
2.Call CyberPower at (952)
3.When you contact CyberPower, identify the Product, the Purchase Date, and request Return Materials Authorization (RMA) information from CyberPower.
4.Pack and ship the Product to CyberPower as instructed in your RMA. Show the RMA code on the shipping label or include it with the Product. You MUST prepay all shipping costs and you are responsible for packaging and shipment.
CyberPower will inspect and examine the Product within ten (10) days of receipt. If the Product is not as warranted, CyberPower will repair or replace the Product and return it to you at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required).
POWER CONTROL GUARANTEE
If you are the Initial Purchaser, the Power Control Guarantee provides protection for damage to equipment connected to the Product ("Connected Equipment"), subject to certain terms and limitations.
The Power Control Guarantee is not "first dollar" coverage. CyberPower's obligation is reduced by any amounts that Initial Customer is entitled to recover from other sources regarding the Connected Equipment, including insurance, other warranty, or extended warranty coverage, whether or not the Initial Customer makes a claim for recovery, including but not limited to a claim under any applicable insurance, other warranty, or extended warranty.
The Limited Warranty does not cover Connected Equipment, but as is explained below, to be covered under the Power Control Guarantee, the Connected Equipment must have been damaged due to a failure of the Product. The Connected Equipment must have been damaged due to a defect in materials or workmanship of the Product.
In the event of damage to the Connected Equipment, your exclusive remedy, and CyberPower's sole obligations are as follows for Connected Equipment. If (a) the Product purchased and owned by you is defective in material or workmanship; (b) the Limited Warranty requirements have been met (except that the three year limitation of the Limited Warranty does not limit the Power Control Guarantee, which is for the lifetime of the Product), and; (c) none of the limitations or exclusions on warranty coverage apply (or than the three year limit), CyberPower will (as CyberPower elects, as permitted by law), repair, replace, or pay the Agreed Damage Amount (defined below) for, the item(s) of your electronic equipment directly and properly connected to the product (the "Connected Equipment") if that Connected Equipment is (x) damaged by AC power line transients, spikes, or surges on properly installed, grounded, and
Making a Power Control Guarantee Claim.
To make a Warranty claim for damage to Connected Equipment under the Power Control Guarantee, you must do the following:
1.Complete and return the CyberPower Warranty card or provide reasonable proof of purchase, for example, a sales receipt that establishes you as the original
2.Call CyberPower at (952)
3.When you contact CyberPower, identify the Product, the Purchase Date, and the item(s) of Connected Equipment. Have information on all applicable insurance or other resources of recovery/payment that are available to the Initial Customer and the name of the power utility supplier for the location of the Connected Equipment and Request a Return Materials Authorization (RMA).
4.Pack and ship the product to CyberPower and, if requested, the item(s) of Connected Equipment, a repair cost estimate for the damage to the Connected Equipment, and all claim forms that CyberPower provides to you. Show the RMA number on the shipping label or include it with the product. You must prepay all shipping costs, must pay the cost of the repair estimate and is responsible for packaging and shipment.
CyberPower's Duties.
CyberPower will inspect and examine the Product and the item(s) of Connected Equipment (or at CyberPower's election, your written statement and repair cost estimate for those item(s)). You must return the product for inspection.
If the damage to Connected Equipment is covered by the Power Control Guarantee, CyberPower will (in addition to Limited Warranty remedies for the CyberPower Product itself) repair (or pay the costs of repair) or replace the Connected Equipment or, at the option of CyberPower, as permitted by law, pay to the Initial Customer the "Agreed Damage Amount" (up to the aggregate limits stated below) for all item(s) of Initial Customer's Connected Equipment. The "Agreed Damage Amount" for all items of Initial Customer's Connected Equipment shall be the lesser of the amount determined under Clause
(1) or (2) below, reduced by any amounts described in Clause (3) below:
1.The fair market value of the Connected Equipment as established by the lower of (a) the average price the same or similar items are being sold for on
Blue Book on the date of occurrence (or if such price list is no longer published, a published or announced price list reasonably selected by CyberPower), or (c) the lowest price the same or similar items can be purchased for in the United States.
2.The aggregate ceiling amount for all Connected Equipment: CyberPower
3.The amount(s) of all payment you have or are entitled to receive from insurance, other warranties, extended warranties, or from other sources or persons for the Connected Equipment or damage to such equipment so that CyberPower¡¦s maximum liability shall be reduced to reflect all such other payments or sources of recovery
If CyberPower replaces the connected equipment or pays to the Initial Customer the Agreed Damage Amount, the Initial Customer shall transfer all item(s) to CyberPower without warranty by the Initial Customer, but free of lien or other interest.
CONDITIONS COMMON TO THE LIMITED WARRANTY AND THE POWER CONTROL GUARANTEE
The Limited Warranty and the Power Control Guarantee are the only and the exclusive express warranty of CyberPower with respect to the Product. This exclusion of other express warranties applies to written and oral express warranties.
LIMITATION: THE LIMITED WARRANTY AND THE POWER CONTROL GUARANTEE DO NOT COVER
The Limited Warranty and the Power Control Guarantee are intended to exclusive rights and remedies and replace any other rights, to the extent allowed by law.
1.As to the CyberPower Product, the limited warranty does not cover or apply to: misuse, modification, operation or storage outside environmental limits for the Products, in transit, in shipment, or in storage, damage or deterioration, improper operation or maintenance, or use with items or equipment not designed or intended for use with the product.
2.As to Connected Equipment, the Power Control Guarantee covers only damage within the specific terms of the Power Control Guarantee to Connected Equipment (and only up to the applicable aggregate ceiling amount).
3.The Power Control Guarantee does not cover damage to Connected Equipment or apply if the Product has been operated in a failure mode or not in compliance with CyberPower operating instructions and manuals, or if the Connected Equipment has been operated in a failure mode or not in compliance with the instructions and manuals of its manufacturer/vendor.
The Limited Warranty and the Power Control Guarantee Do Not Apply Unless The Initial Customer:
1.Has properly connected the Product and the Connected Equipment to properly wired and grounded outlets (including compliance with electrical and safety codes of the most
current electrical code (ANS/NFPA 70), without the use of any adapters, extension cords of other connectors.
2.Has provided a suitable and proper environment for use and installation of the Product and Connected Equipment.
3.Has properly installed and operated the CyberPower Product and Connected equipment.
4.Has operated the Product at all times within the limitations on the Product¡¦s VA capacity as stated in this User Manual.
CyberPower Does Not Cover or Undertake Any Liability in Any Event for Any of the Following:
1.Loss of or damage to data, records, or software or the restoration of data or records, or the reinstallation of software.
2.Damage from causes other than AC Power Line Transients, spikes, or surges on properly installed, grounded and
3.Damage from any circumstance described as excluded above with respect to the product.
4.Damages from fire, flood, wind, rain, rising water, leakage or breakage of plumbing, abuse, misuse or alteration of either the product or the Connected Equipment.
Exclusion of Consequential and Other Damages.
The sole and exclusive remedies of the Initial Customer are those provided by the Limited Warranty and Power Control Guarantee. CyberPower excludes any liability for personal injury under the Limited Warranty and Power Control Guarantee. CyberPower excludes any liability for direct, indirect, special, incidental or consequential damages, whether for damage to or loss of property [EXCEPT FOR (AND ONLY FOR) the specific limited agreement of CYBERPOWER to provide certain warranty benefits regarding "Connected Equipment" under the "CYBERPOWER Power Control Guarantee"], loss of profits, business interruption, loss of information or data. This exclusion applies even though damage or loss is caused by negligence or other fault. NOTE: Some States or Provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply to you.
DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT OR OTHER HIGH RISK ACTIVITIES.
CyberPower does not sell the Products for use in
CyberPower does not authorize use of any of its products in any High Risk Activity. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF
A CYBERPOWER PRODUCT.
The Limited Warranty and the Power Control Guarantee are governed by the laws of the United States and the State of Minnesota, without reference to conflict of law principles. The
application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded.
Contact Information: CyberPower's address is 4241 12th Ave East, Suite 400, Shakopee, MN 55379 and its phone number is (952) 403- 9500 or (877)
