1. Slide the battery latch assembly into place.
2. Replace the spring.
3. Align the battery release button with the hole in the battery latch assembly, then press the button into place.
4. Follow the steps in Removing the Battery Latch Assembly in the reverse order.
Back to Contents Page
1
plastic grip
2
battery latch assembly
3
spring
NOTICE: Before you remove the battery release button, observe the orientation of the button to ensure proper installation when the button is
replaced.
CAUTION: Before you begin the following procedure, follow the safety instructions in the Product Information Guide.
NOTICE: Ensure the battery latch assembly is properly oriented. The indent for the screw should face up when installing the assembly.
