On-screen guide icons

Preliminary knowledge

English

During DVD VIDEO playback, you may see icons displayed over the picture. These have the following meanings.

: Displayed at the beginning of a scene recorded from multiple angles. (See page 41.)

:Displayed at the beginning of a scene recorded with multiple audio languages. (See page 44.)

:Displayed at the beginning of a scene recorded with multiple subtitle languages. (See page 43.)

You can set the unit not to display on-screen icons above via the preference settings described on page 55.

About invalid operation icon

When you press a button, if the unit does not accept its operation, appears on your

television screen. Operations are occasionally unacceptable even if is not displayed.

Note that some operations may not be accepted. For example, some discs may not allow rapid advance/reverse or slow-motion playback.

Preliminary

knowledge





How to use numeric buttons

The function of the numeric buttons differs depending on the setting of the TV - DVD switch. When setting it to TV, the buttons are used to select a TV channel (see page 23).

TV DVDWhen setting it to DVD, the buttons are used to select a track/title/group or enter a disc time or chapter number.

REPEAT

3D

TV/VIDEO

PHONIC

CANCEL

RETURN

TV1

TV2

TV3

1

2

3

TV4

TV5

TV6

4

5

6

TV7

TV8

TV9

7

8

9

TV -/--

TV0

MUTING

10

0

+10

ANGLE

SUBTITLE

AUDIO

VFP





S.FREQ

PROGRESSIVE







C

TV DVD

To select a track/title/group number

•To select a number between 1 and 10

Press the corresponding button for the number.

•To select a number higher than 10 Use the +10 button.

Examples:



→ 3



To select 13

+10



To select 34

+10

→ +10 → +10

→ 4

To select 40

+10

→ +10 → +10

→ 10

To enter a time or chapter number

The method for entering a time for Time search or chapter number for Chapter search is different from above. See the corresponding sections in this manual for the details.

*There is another method for selecting a track or group of an MP3 disc. See the appropriate section.

To select a TV channel

Press the corresponding numeric buttons. See page 23 and 24 for details.

13
