REFRIGERATOR LINER PARTS

For Model: KSSC42QMS03 (Stainless Steel)

Illus. Part

No. No. DESCRIPTION

1Liner (Not A Serviceable Part)

22306010 Thermistor

32208970 Air Duct

42209204 Clip, Thermistor

52259077 Ladder, Shelf (2)

6520965 Screw Support, Ladder (8)

72006475 Screw

8487539 Screw

92302937 Thermistor

102302986 Lid, Meat Pan Baffle

112320635 Baffle Control Assembly

122171846 Release Valve

132310205 Jumper, Air Baffle

14488357 Screw

15486194 Screw

172221296 Air Baffle Assembly

182320660 Reservoir

19488280 Screw

212309222 Diffuser Assembly

222317105 Cover, Thermistor

232188820 Thermistor

242302992 Spacer, Air− Baffle

252309087 Cover, Diffuser

272259412 Seal, Air Duct

(Round Hole)

282259398 Seal, Air Duct (Square Hole)

6

W10114883

Page 6
