4026-0XX



FRU

Action







2

Toner Car-

Replace the toner cartridge if the cartridge is



tridge

nearing the end of life.







3

Transfer

Check the transfer roll for toner buildup and con-



Assembly

tamination. Clean the transfer roll by performing





POST two or three times.





Light print or black vertical streaks can be





caused by an open transfer leakage current cir-





cuit. Check the transfer roll right side contact,





TFR board lead and the TFR Leakage board





(PWB-T) for damage or poor contact.





If light print is still a problem, replace the follow-





ing FRUs one at a time in the order shown:





HVPS





Transfer Assembly





TFR Leakage board PWB-T





Engine board







Toner on backside of printed page

Note: Toner on the back of the printed page can be caused by poor fusing, improper development, or incorrect charging.



FRU

Action







1

Fuser Assem-

Check the hot roll and backup roll for toner



bly

buildup. Clean or replace as necessary.





If the fuser assembly is clean and functioning





correctly, replace the following FRUs one at a





time in the order shown:





HVPS





Engine board







Diagnostic Information 2-43
