SAMSUNG DVM-Pro 2008 User Guide
5-8. Indoor units not yet attached
-. In case of there is unconnected Indoor unit, piping connection mode is not activated.
-. Delete it by delete command after select no needful indoor among unconnected Indoor unit
6. Piping
6-1. Workspace : It shows the details information about workspace that displays and can change, and uses workspace that is using present in workspace selection window. -. Choose workspace that wish to work.
6-2. Piping
6-2-1. Select Outdoor
Can select ONLY piping system diagram of Outdoor unit wanting in the same workspace.
6-2-2. Select Piping connection tool
If User starts to draw Piping diagram after translate to manual Pipe, it will be activated. It's ok if drag and drop the connection tool to need when design by manual Pipe.
6-2-3. basic pipe, standard Pipe and manual Pipe : User can apply any pipe.
-. Basic Pipe : Piping design way to connect all indoors on one of main pipe-line.
-. Standard Pipe : DVM Pro recommends this way.
All Indoors would be got a way alike distributed as 50 to 50 rate.
-. Manual Pipe : User can edit the Piping at free.
