SAMSUNG DVM-Pro 2008 User Guide

c. Add / delete floor : Can create or delete additional floor after make the floor. . -. New floor is added if enter building code and name after press [add floor].

*Can’t duplicate the code name and the code are configured with alphabet and Arabic.

d. Edit Floor height : Edit current floor height.

-. Edit the floor height after select the relevant position of floor under title of floor height.

-.Can edit the height of one floor and several floor using CTRL+ c and CTRL+ v if want to be same floor in different floor, too.

e. Link file : Connect the drawing file to be used to project.

-.Because drawing connection means to link only one file, it must be architecture basis drawing of all floors in a file.

*Drawing connection does not mean to connect the each file. -. Select any space under title that is a file in floor area.

-. Select drawing to connect after press [link file], and presses confirmation.

3-3. Setup Workspace :

User can define the same refrigerant, product series and A/C type to one standard unit. All works is done by workspace base. If chooses indoor unit in one workspace, choose Outdoor unit that is correct for the product automatically. If do not choose workspace, can't move to the step of Indoor unit that is next step.

-. Press [setup workspace] Enter name

Choose the refrigerant piping, product series, A/C type and building. If press addition button, it's added on workspace area of right-side.

Can edit or delete according to need.

-. It shows Workspace's status that is added on workspace inquiry window of screen right- side.
