Fig.A-2 POWER UNIT (2)

Key#

PART NUMBER

DESCRIPTION

Q'TY

NOTE

/UNIT



















1

3356-24101

Brake band comp.

1



2

3356-24111

• Band

1



3

3356-24120

• Arm

1



4

04025-00408

• Pin

1



5

3356-24140

Roller

1



6

2622-24210

Lever

1



7

848-C92-5431

Stopper

1



8

2622-24600

Spring

1



9

3356-24240

Spring

1



10

0308-00060

Snap ring

2



11

2623-25310

Spike

1



12

2616-25320

Screw

2



13

3356-26100

Cap assy

1



14

3317-57220

• Gasket

1



15

848-C90-3114

Cover comp.

1



16

3356-31120

• Cap

1



17

3356-31152

• Grommet

1



18

3356-31212

Seal

1



19

0263-90514

Screw

2



20

0263-90520

Screw

1



21

2620-32100

Left handle comp.

1



22

2851-32180

Plate

2



23

848-825-1901

Screw

4



24

2622-33005

Right handle assy

1



25

2622-33105

• Right handle comp.

1



26

3350-33220

• Plate

1



27

3330-33250

• Stopper

1



28

3310-33262

• Spring

1



29

3310-33271

• Knob

1



30

2810-33280

• Damper (A)

1



31

848-C10-33C3

• Lever

1



32

3356-33321

• Spring

1



33

04025-00524

• Pin

1



34

2616-33412

• Damper (B)

1



35

3356-34111

Cover

1



36

848-C30-33E3

Arm

1



37

3356-32210

Screw

1



38

3350-34400

Cap assy

1



39

3350-26110

• Cap

1



40

3317-57230

• Chain

1



41

3317-57240

• Stopper

1



42

0277-10410

• Screw

1



43

3350-34450

• Gasket

1



44

3350-51110

Drum

1



45

3360-51120

Sprocket

1

3/8Px7T

46

3356-53003

Chain cover assy

1



47

3356-53220

• Plate

1

K8

48

0277-10410

• Screw





49

3350-53410

Nut

2



50

3356-53210

Plate

1



51

0261-00410

Screw

1



53

2616-71112

Rotor

1



54

848-C90-71B1

Source coil

1



55

2616-71301

Ignition coil comp.

1



56

2616-71320

• Cap

1



57

2616-71331

• Cord

1



58

2616-71410

Cord

1



59

2616-71420

Cord

1



















G621AVS

Key#

PART NUMBER

DESCRIPTION

Q'TY

NOTE

/UNIT



















60

2616-71430

Cord

1



61

2618-71102

Rotor comp.

1



62

3366-71120

• Ratchet

2



63

3350-71131

• Spring

2



64

3388-71150

• Washer

2



65

3310-71142

• Boft

2



66

2850-72110

Cap

1



67

1400-72121

Spring

1



68

2850-71320

Tube

1



69

3350-15250

Bolt

2



70

0263-30416

Screw

2



71

3699-90002-10

Spark plug

1

CJ-7Y

72

3369-81000

Carburetor

1

See Fig.B

73

848-C91-8311

Air cleaner comp.

1

Net type

74

848-C90-83C0

• Plate

1



75

3369-83200

Silencer

1



76

2622-83302

Cover comp.

1



77

3356-83322

• Knob

1



78

3388-83340

• Gasket

1



79

3369-31163

Label

1



81

3359-53121

Label

1



82

3369-75131

Label

1



101

2610-83220

Cap

1

OP

102

2623-06012

Double spike kit

1

OP

103

2618-53002 • Chain cover assy

1

OP

104

3356-53220

• • Plate

1



105

0261-00410

• • Screw

1

K8

106

2616-53300

• • Protector

1

OP, K8

107

2618-53510

• Spike

1

OP, K8

108

3310-53331

• Nut

2

OP, K8

109

2670-14320

• Screw

2

OP, K8

110

2626-31110

Cover

1

OP

27
