3.4.Integrated Peripherals

øThis menu allows you to control the various ports of the computer such as IDE, SATA, USB, IEEE1394, COM port, LPT port, AC97 audio, etc.

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

Integrated Peripherals

	On-Chip Primary PCI IDE		[Enabled]			Item Help
	On-Chip Secondary PCI IDE		[Enabled]			Menu Level}
	IDE1 Conductor Cable		[Auto]			If a hard disk
	IDE2 Conductor Cable		[Auto]			controller card is
	USB Controller		[Enabled]			used, set at Disabled
	USB Keyboard Support		[Disabled]
	USB Mouse Support		[Disabled]			[Enabled]
	AC97 Audio		[Auto]			Enable onboard IDE
	Onboard H/W LAN		[Enabled]			PORT
	Onboard LAN Boot ROM		[Disabled]
	Onboard Serial Port 1		[3F8/IRQ4]			[Disabled]
	Onboard Serial Port 2		[2F8/IRQ3]			Disable onboard IDE
	UART Mode Select		[Normal]			PORT
x	UR2 Duplex Mode		Half
x	TxD,RxD Polarity Active		Lo,Hi
x	Use IR Pins		IR-Rx2Tx2
	Onboard Parallel Port		[378/IRQ7]
	Parallel Port Mode		[SPP]
x	ECP Mode Use DMA		3
	Game Port Address		[201]
	Midi Port Address		[Disabled]
x	Midi Port IRQ		10
higf: Move		Enter: Select	+/-/PU/PD: Value	F10: Save	ESC: Exit		F1: General Help
	F5: Previous Values		F6: Fail-Save Default		F7: Optimized Defaults

nOn-Chip Primary PCI IDE

Allows the user to enable or disable the first onboard IDE channel. (default:Enabled)

nOn-Chip Secondary PCI IDE

Allows the user to enable or disable the second onboard IDE channel. (default:Enabled)

nIDE1 Conductor Cable

Allows user to select the type of IDE1 conductor cable. Prior to selecting the setting,

please make sure that the IDE device and cables support the desired setting.

Options: Auto, ATA66/100, ATA33 (default:Auto)

nIDE2 Conductor Cable

Allows user to select the type of IDE2 conductor cable. Prior to selecting the setting, please make sure that the IDE device and cables support the desired setting. Options: Auto, ATA66/100, ATA33 (default:Auto)

nUSB Controller

Allows the user to enable or disable the onboard USB2.0 controller. (default:Enabled)

nUSB Keyboard Support

Allows user to use a USB-based keyboard (Enable if you are using a USB keyboard, otherwise Disable) (default:Disabled)
