CHAPTER 4 CIRCUIT CARD INFORMATION

List of Required Circuit Card

LIST OF REQUIRED CIRCUIT CARD

Table 4-1shows the required circuit cards to be explained in this section.

Table 4-1 List of Required Circuit Card

			EXTRACTION/
			INSERTION WITH
NAME	LAMP	SWITCH	POWER ON
	X: PROVIDED	X: PROVIDED	X: ALLOWED	REFERENCE
(FUNCTIONAL
	–: NOT	–: NOT	: ALLOWED	PAGE
NAME)
	PROVIDED	PROVIDED	AFTER MB*
			–: NOT
			ALLOWED
PN-CP14 (MP)	X	X	–	Page 45
PN-30DTC-A (DTI)	X	X		Page 50
PN-24DTA-C (DTI)	X	X		Page 56
PN-SC01 (DCH)	X	X		Page 62
PZ-M542 (CONN)	–	X	X	Page 65
PZ-M557 (CONN)	–	X	X	Page 67

*MB = Make Busy
