Installation and Set-Up





























1.2 Set-Up

Moving within a Set-Up Menu









Use the arrow keys ( ,





,





,



) to move among the menus or









within a list, or to select

buttons.

































In a



























menu . . .



Indicates . . .

































A pull-right submenu is available.



. . .





A dialog box is available for you to specify more information.



a





The menu￿

item with

the

filled-in circle is enabled. Only one



b





of these items can be enabled at a time.



c



































The menu item with the checkbox is enabled.



























Press







Do

or





to start the action or to choose the

Enter



Return



Select































currentlyhighlighted feature.

A dimmed menu item does not apply to the currently selected mode.

Caution

If you disable the Display CRT Saver feature, an image

may etch onto the screen, whichmay shorten the terminal's useful life.

Installation and Set-Up 1–5
