Chapter 40 Cisco IP Phones

Phone Button Templates

Table 40-2 Default Phone Button Templates Listed by Model (continued)

Cisco IP Phone Model

Default Phone Button Template Description





Cisco IP Phone 7910

The default phone button template for the



Cisco IP Phone 7910 uses button 1 for message



waiting, button 2 for conference, button 3 for



forwarding, buttons 4 and 5 for speed dial, and button



6 for redial.



The Cisco IP Phone 7910 includes fixed buttons for



Line, Hold, Transfer, and Settings.





Cisco IP Phone 7905

The default phone button template for the



Cisco IP Phone 7905 uses button 1 for line 1, buttons



2 through 5 for speed dial, button 6 for Hold, and



button 7 for Settings.





Cisco IP Phone 7902

The default phone button template for the



Cisco IP Phone 7902 uses button 1 for line 1, buttons



2 through 5 for speed dial, button 6 for Hold, and



button 7 for Settings.





Cisco IP Conference

The default phone button template, which is not

Station 7936

configurable, for the Cisco IP Conference Station 7936



uses button 1 for line 1.





Cisco IP Conference

The default phone button template, which is not

Station 7935

configurable, for the Cisco IP Conference Station 7935



uses button 1 for line 1.





Cisco IP Phone 30 SP+

The default Cisco IP Phone model 30 SP+ template



uses buttons 1 through 4 for lines, and button 5 for call



park; button 6 through 8 and 17 through 21 remain



undefined, and button 9 through 13 and 22 through 25



apply for speed dial; button 14 applies for message



waiting indicator, button 15 for forward, and button 16



for conference.



Note For only the Cisco IP Phone model 30 SP+,



assign button 26 for automatic echo



cancellation (AEC).







Cisco CallManager System Guide

40-14

OL-7135-01
