Operación básica continuación

Para todos los modelos—Botón “MUTE/TEST” (Silencio/Prueba):

Para silenciar las alarmas UPS: Presione brevemente el botón MUTE/TEST (Silencio/Prueba) y luego suéltelo.*

Para ejecutar una auto-prueba: Con su UPS conectado y encendido, presione y mantenga presionado el botón MUTE/TEST (Silencio/Prueba) por dos segundos.* Siga presionando el botón hasta que la alarma suene varias veces y el UPS realice una auto-prueba. Vea “Resultados de una auto-prueba” más adelante. Nota: Puede dejar equipos conectados durante una auto-prueba, pero el UPS no realizará una auto-prueba si no está encendido (vea la descripción del botón “POWER”).

¡PRECAUCIÓN! No desconecte su UPS para probar sus baterías. Esto eliminaría la conexión de seguridad a tierra y podría introducir una sobretensión dañina en sus conexiones de red.

Resultados de una auto-prueba: La prueba durará cerca de 10 segundos mientras el UPS conmuta a batería para probar su capacidad de carga y la recarga de la batería.**

Si el LED “OUTPUT LOAD LEVEL” (Nivel de carga de salida) permanece encendido rojo y la alarma continúa sonando después de la prueba, las salidas del UPS están sobrecargadas. Para eliminar la sobrecarga, desconecte algo de su equipo y ejecute la auto-prueba repetidamente hasta que el LED ya no esté encendido rojo y la alarma ya no esté sonando.

¡PRECAUCIÓN! Cualquier sobrecarga que no sea corregida por el usuario inmediatamente después de una auto-prueba puede causar que el UPS se apague y deje de suministrar energía en el caso de un falla del servicio eléctrico o una baja de voltaje severa.

Si el LED “BATTERY WARNING” (Advertencia de batería) sigue encendido y la alarma continúa sonando después de la prueba, las baterías del UPS deben recargarse o reemplazarse. Permita que el UPS se recargue continuamente por 12 horas y repita la auto-prueba. Si el LED permanece encendido, contacte con Tripp Lite para obtener servicio. Si su UPS requiere el reemplazo de su batería, visite www.tripplite.com/support/battery/index.cfm para localizar una batería de reemplazo Tripp Lite específica para su UPS.

*La alarma emitirá un pitido brevemente después de pasado el intervalo indicado. ** Operación de los modelos SmartPro durante la auto-prueba: El LED “POWER” (Alimentación) estará destellando, los LED “OUTPUT LOAD LEVEL” (Nivel de carga de salida) y “BATTERY CHARGE” (Carga de batería) estarán encendidos y la alarma UPS sonará. Operación de los modelos OmniSmart durante la auto-prueba: Todos los LED estarán encendidos y la alarma UPS sonará.

18
