Network

IES-5000/5005/6000 Support Notes

Syslog server

Network

Uplink

IES-5000

ALC-1248G

SLC-1248G

ADSL/SHDSL

modem

Setting up a Syslog server

In this section, we will show you how to configure the IES-5000 and Kiwi Syslog server. The subsequent sections describe the detailed configuration steps.

1. Installing and Running Kiwi’s Syslog Server

Download the Kiwi syslog daemon installation file from the web site and double-click the file to start the installation process. Follow the on-screen description to install.

74

All contents copyright (c) 2008 ZyXEL Communications Corporation.
