2. CPE settings

IES-5000/5005/6000 Support Notes

2. CPE settings

Connect a CPE device to DSL port 25. Refer to the previous sections on how to configure the CPE device.

3. IP Commander settings

Display the IP Commander screen and right-click on IP Commander and then click Connect New Server”.

Enter the IP address (for example, 192.168.1.99) or domain name of the DHCP server and click OK.

87
