Package Contents, System Requirements

Package Contents

1 x GCS1108 8-port USB DVI KVMP Switch 2 x Custom USB DVI-D KVM Cable Sets

1 x Firmware Upgrade Cable

1 x Power Adapter

1 x Foot Pad Set (4 pcs)

1 x User Manual

1 x Rack Mount Kit

1 x Warranty Card

System Requirements

Recommended Console

•Display Option #1 – A display with both DVI and VGA connection*

•Display Option #2 – A DVI-I Display for DVI computers

•Display Option #3 – One each of DVI and VGA displays to support DVI and VGA computers

•1 set of USB keyboard and mouse

Computers

•1 DVI port or 1 VGA port

•1 USB port

Operating Systems

•Windows XP, Windows Vista (32-bit / 64-bit)

•Windows 7 (32-bit / 64-bit)**

•Mac OS X v10.3.9 or later

•Sun Solaris

•Linux

*IOGEAR recommends Display Option #1 for best display configuration

**IOGEAR's Display Emulation Technology provides the EDID support for Windows 7

Cable

Only custom USB DVI or VGA KVM cable sets, which are specifically designed to work with this switch, may be used to link to the computers. Two cable sets are provided with this package.

Note: The quality of the display is affected by the quality and length of the cables. If you need additional cable sets, please contact your dealer to purchase the appropriate ones for your switch.

Type	Length	Part Number

	6ft (1.8m)	G2L7D02U

USB DVI-D Single Link	10ft (3.0 m)	G2L7D03U
	15ft (5.0 m)	G2L7D05U

USB DVI-I Single Link*	6ft (1.8 m)	G2L7D02UI *
	10ft (3.0 m)	G2L7D03UI

Tyep	Length	Part Number

USB VGA	6ft (1.8m)	G2L5102U
Cable

DVI-A Adapter		GDVIMVGAF

*For cascading setup, IOGEAR recommends to use USB DVI-I Single Link cable (G2L7D02UI) for best performance use.
