LG Electronics 42LS75A 49LS75A 55LS75A owner manual External Device Connection

Page 18

ENGLISH

18MAKING CONNECTIONS

External Device Connection

Connect a HD receiver, DVD, or VCR player to the monitor and select an appropriate input mode.

The illustrations may differ from the actual accessories. Some of the cables are not provided. For the best picture and sound quality, connecting external devices to your monitor using HDMI cables is recommended.

Direct Connection/

Using the Router/

Using the Internet

OR

USB

(not included)

(not included)

Network

3.3V ___ 0.25mA

---

HDMI

HD Receiver/DVD/VCR

Camcorder/Camera/Gaming Device

Image 18
