Page 22

22ENTERTAINMENT

ENGLISH

Using the Input List

Remote Control (HOME)

	Input Mode	Description
	HDMI1	You can watch content on a PC,
	HDMI2/OPS	You can watch content on a PC,
	HDMI2/OPS	DVD player, digital set-top box,

	DISPLAYPORT
	DISPLAYPORT	and other high definition devices.
	DVI

CAUTION

••If the OPS kit is connected to the HDMI2/ OPS port, the HDMI2/OPS port is used as the OPS port.

ENTERTAINMENT

Using My Media

Connecting USB storage devices

Connect a USB storage device such as a USB flash memory or an external hard drive to the display and use multimedia features.

Connect a USB flash memory or USB memory card reader to the display as shown in the following illustration.

OR

CAUTION

••Do not turn off the monitor or remove a USB storage device when the My Media screen is activated. This could result in loss of files or damage to the USB storage device.

••Back up files you have saved on a USB storage device frequently, as loss or damage to the files may be not covered by the warranty.
