Page 48

		48 PRODUCT SPECIFICATIONS
	ENGLISH	Dimensions (Width
	ENGLISH	x Height x Depth) /
		x Height x Depth) /
		Weight
		1094.6 mm x 637.4 mm x 31.7 mm / 15.6 kg
		1094.6 mm x 699.7 mm x 298.3 mm / 17.0 kg
		1094.6 mm x 637.4 mm x 81.3 mm / 16.4 kg
		1094.6 mm x 699.7 mm x 298.3 mm / 17.8 kg

* Applicable only for models that support the speakers

Audio/AUDIO	RMS Audio Output	10 W + 10 W (R + L)

	Input Sensitivity	0.7 Vrms

	Speaker Impedance	8 Ω

The specifications shown above may be changed without prior notice to improve quality.
