AMD GA-MA69VM-S2 user manual OnChip IDE Channel0, OnChip Sata Controller, OnChip Sata Type

Page 36

English

2-3

Integrated Peripherals











CMOS Setup Utility-Copyright (C) 1984-2007 Award Software









Integrated Peripherals





`

IDE Configuration

[Press Enter]

Item Help



OnChip SATA Controller

[Enabled]



Menu Level`



OnChip SATA Type

[Native IDE]







Onboard Audio Function

[Auto]









Onboard LAN Function

[Enabld]









Onboard LAN Boot ROM

[Disabled]









OnChip USB Controller

[Enabled]









USB EHCI Controller

[Enabled]









USB Keyboard Support

[Enabled]









USB Mouse Support

[Disabled]









Legacy USB storage detect

[Enabled]









Onboard Serial Port 1

[3F8/IRQ4]







Onboard Serial Port 2

[2F8/IRQ3]







Onboard Parallel Port

[378/IRQ7]







Parallel Port Mode

[SPP]







x ECP Mode Use DMA

3







KLJI: Move

Enter: Select

+/-/PU/PD: Value

F10: Save

ESC: Exit

F1: General Help



F5: Previous Values

F6: Fail-Safe Defaults



F7: Optimized Defaults















IDE Configuration













CMOS Setup Utility-Copyright (C) 1984-2007 Award Software









IDE Configuration







OnChip IDE Channel0

[Enabled]



Item Help











Menu Level`

KLJI: Move

Enter: Select

+/-/PU/PD: Value

F10: Save

ESC: Exit

F1: General Help

F5: Previous Values

F6: Fail-Safe Defaults



F7: Optimized Defaults

OnChip IDE Channel0

Enabled

Enable onboard 1st channel IDE port. (Default value)

Disabled

Disable onboard 1st channel IDE port.

OnChip SATA Controller

Enabled

Enable onboard SATA function. (Default value)

Disabled

Disable onboard SATA function.

OnChip SATA Type

Native IDE

Set the SATA channel to Native IDE mode.(Default value)

RAID

Set the SATA channel to RAID mode.

Legacy IDE

Set the SATA channel to Legacy IDE mode.

SATAJAHCI

Set the SATA channel to AHCI mode. Advanced Host Controller Interface (AHCI)



is an interface specification that allows the storage driver to enable advanced



Serial ATA features such as Native Command Queuing and hot plug.

GA-MA69VM-S2 Motherboard

- 36 -
