CHAPTER 1 Hardware

Descriptions

This chapter provides a visual tour of the external hardware features of the WatchGuard® Firebox® V10, V60, V80, and V100 security appliances, focusing on the buttons, LEDs, interfaces, ports. Please see the Fire- box Vclass User Guide for installation instructions.

Package Contents

Each appliance model is packaged with different con- tents, as described in this section.

WatchGuard Firebox V10 security appliance

•One 12V 1.25A, power supply

•Two green, straight-through, 10/100 BaseT, Ethernet cables

•A CD containing the WatchGuard Vcontroller application software for use with three different operating systems: Windows 2000/XP, Solaris,
