Page 46

-Control Temperature High/Low

These items set the high and low temperature limit that you want to do the fan speed control.

-DC Fan Voltage High/Low

These items set the high and low voltage limit that you want to provide the fan with.

The value of high limit must be set above the one of low limit.

3rd FanEQ Group

Click <Enter> key to enter its submenu (3rd FanEQ Group):

µGuru Utility V1.00C

ABIT EQ

3rd FanEQ Group

OTES1 FanEQ Control



Enabled

Item Help ►►►

-Reference Temperature

SYS Temperature



-Control Temperature

High

40°C/104°F



-Control Temperature

Low

30°C/86°F



-DC Fan Voltage High



12.0 V



-DC Fan Voltage Low



8.0 V



OTES2 FanEQ Control



Disabled











￿￿￿￿:Move Enter:Select +/-/PU/PD:Value

F10:Save ESC:Exit

OTES1~OTES2 FanEQ Control

When set to [Enabled], these items control the OTES1~OTES2 fan speed by the following setting combinations.

-Reference Temperature

This item selects the reference point for taking temperature among the available options of CPU, SYS, and PWM Temperature, but there is only one “CPU Temperature” item to choose for the “CPU FanEQ Control”.

-Control Temperature High/Low

These items set the high and low temperature limit that you want to do the fan speed control.

-DC Fan Voltage High/Low

These items set the high and low voltage limit that you want to provide the fan with.

The value of high limit must be set above the one of low limit.

3-10

AW9D-MAX, AW9D
