Page 17

7

ML2(p)

8

GND

9

ML2(n)

10

ML3(p)

11

GND

12

ML3(n)

13

GND

14

GND

15

AUX(p)

16

GND

17

AUX(n)

18

HPD

19

DP_PWR Return

20

+3.3V DP_PWR

Plug and Play Capability

You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display Identification Data (EDID) using Display Data Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. Most monitor installations are automatic; you can select different settings if desired. For more information about changing the monitor settings, see Operating the Monitor.

Universal Serial Bus (USB) Interface

This section gives you information about the USB ports that are available on the left side of your monitor.

NOTE: This monitor supports High-Speed Certified USB 2.0 interface.

Transfer speed



Data



Power Consumption





Rate





High speed



480 Mbps



2.5W (Max., each port)

Full speed



12 Mbps



2.5W (Max., each port)





Low speed



1.5 Mbps



2.5W (Max., each port)

USB Upstream Connector
