Filters and QoS Configuration for ERS 5500





Technical Configuration Guide

v2.0

NN48500-559

5. Traffic Meter and Shaping

The Ethernet Routing Switch 5500 supports both policing/metering of ingress traffic in addition to egress port shaping. The meter and shape range is as shown in table 6 below. Please note that all QoS levels are respected and honoured on a shaped interface.

Table 6: Meter and Shaping Range and Granularity

Product

Meter/Shaper Range

Granularity

ERS5510

1 Mbps to 1023 Mbps

1 Mbps

ERS5520

1 Mbps to 1023 Mbps

1 Mbps

ERS5530

64 Kbps to 1023

64 Kbps

(10M/100M,1G)

Mbps



ERS5530 (10G)

1 Mbps to 1023 Gbps

1 Mbps

Bucket Size

8buckets

8buckets

8buckets

12 buckets

When configuring traffic metering or shaping, a committed rate, a maximum burst size and burst duration is entered. The maximum burst rate and burst duration is used along with the committed rate to setup a fixed token bucket where each token represents 1 byte. Up to eight fixed bucket sizes are supported for all 10/100 Mbps and GigE ports. Up to twelve fixed bucket sizes are supported on the ERS5530 only via the 10 GigE interface. The token bucket allows a committed burst to occur up to the token bucket size.

For traffic metering, an in profile and an out of profile action is configured and is expressed as an id. You can use one of the default actions or create a new action prior to configuring a meter. To view the action id’s, please use the command shown below. For example, if you wish to remark the in profile traffic with a QoS level of Bronze and drop traffic for out of profile traffic, select id 3 and 1 respectively. Please note that you must associate the classifier to identify IP traffic since the DSCP value is being remarked.

•5530-24TFD(config)#show qos action

Id

Name

Drop

Update

802.1p

Set Drop Extension

Storage







DSCP

Priority

Precedence

Type

_____ ________________ _____ ______

____________

___________ _________

_______

1

Drop_Traffic

Yes

Ignore

Ignore

High Drop

ReadOnl

2

Standard_Service

No

0x0

Priority 0

High Drop

ReadOnl

3

Bronze_Service

No

0xA

Priority 2

Low Drop

ReadOnl

4

Silver_Service

No

0x12

Priority 3

Low Drop

ReadOnl

5

Gold_Service

No

0x1A

Priority 4

Low Drop

ReadOnl

6

Platinum_Service

No

0x22

Priority 5

Low Drop

ReadOnl

7

Premium_Service

No

0x2E

Priority 6

Low Drop

ReadOnl

8

Network_Service

No

0x30

Priority 7

Low Drop

ReadOnl

9

Null_Action

No

Ignore

Ignore

Low Drop

ReadOnl

55001

UntrustedClfrs1

DPass

Ing 1p

Ignore

Low Drop

Other

55002

UntrustedClfrs2

DPass

0x0

Priority 0

High Drop

Other

.

___________________________________________________________________________________________________________________________
