Filters and QoS Configuration for ERS 5500





Technical Configuration Guide

v2.0

NN48500-559

11.3 Meters

To add a meter, enter the following command:

ERS5500-48T(config)#qos meter <1-64000> name <name> committed-rate <1000- 1023000 Kbit/sec> max-burst-rate <1-4294967295> max-burst-duration <1- 4294967295> in-profile-action <1-64000> out-profile-action <1-64000>

To view the action number, enter the following command:

ERS5500-48T(config)#show qos action



Id

Name

Drop

Update

802.1p

Set Drop Extension

Storage











DSCP

Priority

Precedence

Type

_____

________________ _____

______ ____________

___________ _________

_______

1

Drop_Traffic

Yes

Ignore Ignore

High Drop

ReadOnl

2

Standard_Service DPass

0x0

Priority 0

High Drop

ReadOnl

3

Bronze_Service

DPass

0xA

Priority 2

Low Drop

ReadOnl

4

Silver_Service

DPass

0x12

Priority 3

Low Drop

ReadOnl

5

Gold_Service

DPass

0x1A

Priority 4

Low Drop

ReadOnl

6

Platinum_Service DPass

0x22

Priority 5

Low Drop

ReadOnl

7

Premium_Service

DPass

0x2E

Priority 6

Low Drop

ReadOnl

8

Network_Service

DPass

0x30

Priority 7

Low Drop

ReadOnl

9

Null_Action

DPass

Ignore Ignore

Low Drop

ReadOnl



64001 UntrustedClfrs1

DPass

Ing 1p Ignore

Low Drop

Other



64002 UntrustedClfrs2

DPass

0x0

Priority 0

High Drop

Other

















QoS Meter Command Parameters





















Parameters and variables

Description







<metid>



Enter an integer to specify the QoS meter; range is 1 to 64000.



name <metname>



Specify name for meter; maximum is 16 alphanumeric characters.



committed-rate <rate>



Specifies rate that traffic must not exceed for extended periods to









be considered in-profile. Enter the rate in Kb/s for in-profile traffic









in increments of 1000 Kbits/sec; range is 1000 to 1023000









Kbits/sec.

















max-burst-rate <burstrate>



Specifies the largest burst of traffic that can be received a given









time for the traffic to be considered in-profile. Used in calculating









the committed burst size. Enter the burst size in Kb/s for in-profile









traffic; range is 1 to 4294967295 Kbits/sec













max-burst-duration



Specifies the amount of time that the largest burst of traffic that



<burstdur>



can be received for the traffic to be considered in-profile. Used in









calculating the committed burst size. Enter the burst duration in









ms for in-profile traffic; range is 1 to 4294967295 ms.





in-profile-action <actid>



Specify the in-profile action ID.





in-profile-action-name



Specify the in-profile action name.





<actname>















out-profile-action <actid>



Specify the out-of-profile action ID.





out-profile-action-name



Specify the out-of-profile action name.





<actname>
