LG Electronics 32LQ630H Channel Banks Setup Troubleshooting, Channel Preview/Banks Setup Menu

Page 72

Troubleshooting (Cont.)

Channel Banks Setup Troubleshooting

CHANNEL PREVIEW - BANK 1

CH 011-001

NORMAL-ADDED

Enter -> Change

CC -> VCHIP Menu, Ch. Preview -> Exit

Channel Preview/Banks Setup Menu

Symptom

Possible Cause

Possible Solution

Cannot change channel

Channel Access was denied in Express

Set CH. OVERIDE to 001 to allow access for channel

status in menu.

Script and/or Installer Menu item 028 CH.

status change.



OVERIDE is set to 000.



Channel Preview/Banks

Express Script Installer Menu Wizard/

The Channel Preview/Banks Setup Menu will not be

Setup Menu does not

2-5-5 + MENU (Custom Master TV Setup)

available until the TV setup is transferred to the PTC.

appear.

not completed/performed.

Also, set Installer Menu item 028 CH. OVERIDE to 001





to allow access for channel status changes.

Channel is blanked in all

Blanking a channel in one channel bank



channel banks.

will make it blank in all channel banks.



Cannot tune in deleted



Select a channel bank where the deleted channel number

channel on Channel



is set to NORMAL-ADDED. Direct enter the deleted chan-

Preview/Banks Setup Menu.



nel number. Change to the bank in which you want to





activate the channel. Select “NORMAL-ADDED” on the





Channel Preview/Banks Setup Menu.

“Inactive TV” message

TV is set up to display “Inactive TV”

Select another channel bank (1, 2, or 3) to return TV to

appears and then TV turns

message if all channels are “NORMAL-

normal operation.

OFF.

DELETED” from Channel Bank 4.



Channel found during Auto

Channel was deleted in currently selected

If banks were set up, premium channels may only be

Tuning does not tune in with

channel bank.

available on another channel bank. Select the channel

Channel Up/Down.



bank where the channel is set to NORMAL-ADDED. Or,





direct enter channel number; then go to Channel Preview/





Banks Setup Menu and select “NORMAL-ADDED.”

When BANK on Installer

Installer Menu item 027 HOSPITAL MODE

Set item 027 to appropriate setting for channel banks to

Remote is pressed, TV

is set to 0.

appear with BANK key presses.

shows Input List Menu.











72

206-4207
