Sharp LC-60LE630X, LC-46LE530X, LC-40LE530X Programme setup, Digital settings, Auto installation

Page 12

Checking Signal information (Continued)

Checking Signal information

Press a/b to select “Signal information”.

Programme setup

Digital settings

You can reconfigure DTV services settings automatically or manually.

Auto search Manual search Manual adjust

Signal information

Antenna power

Channel number 68

Signal strength

Current 100 Maximum 100 Signal quality

Current 98 Maximum 98

1

Press MENU and the MENU screen displays.

2

Press c/d to select “Setup”.

3

Press a/b to select “Digital programme setup”,



and then press ENTER. If you have already set the



password, enter it here.



• See page 14 for setting a password.

4Position and align the antenna so that the maximum possible values for “Signal strength” and “Signal quality” are obtained.

NOTE

The values of “Signal strength” and “Signal quality” indicate when to check the appropriate alignment of the antenna.

Auto installation

You can run auto installation again, even after setting up the preset channels.

1Press MENU and the MENU screen displays.

2Press c/d to select “Setup”.

3Press a/b to select “Auto installation”, and then press ENTER.

4If you have already set the password, enter it here.

See page 14 for setting a password.

5Press c/d to select “Yes”, and then press

ENTER.

6Press a/b/c/d to select “DTV”, “ATV” or “ATV

+ DTV”, and then press ENTER.

Press a/b to select the desired sound system, and then press ENTER.

Sound system is selectable when the signal search is set to “ATV” or “ATV + DTV” mode only.

You do not need to do anything during the auto search. Press MENU to exit.

4

Press a/b to select the desired menu item, and

5

then press ENTER.

Press c/d to select “Yes”, and then press



ENTER.

Auto search (Digital)

Use this menu to add new services automatically after auto installation has been completed.

Manual search (Digital)

Add new services within a specified frequency band.

• Press c/d to select the frequency and then press ENTER.

Manual adjust (Digital)

Configure various settings for each service using the Colour (R, G, B) buttons.

Digital programme setup]

1Press a/b to select desired service.

2Press the colour button on the remote control corresponding with the item you want to reconfigure.

Each time the colour button is pressed, you can switch the corresponding operation on/off.

Buttons for Manual adjust operation

Menu

Remote



control

Description

items

buttons

















When the service is locked, you must

Lock

R

enter your password whenever you





tune to the service.





Services with “Skip” are passed over

CH Skip

G

when pressing r/s in the TV/





remote control unit.







Sort

B

The item position of services can be

sorted.





10
