Attaching the stand unit —

4 Attaching the stand cover.



1 Insert the stand cover.



60LE630X

2 Insert and tighten four short screws into the holes of





the

cover

Before performing work, spread cushioning over the surface







on which you will be laying the TV. This will prevent it from







being damaged.





CAUTION





Attach the stand in the correct direction.





Be sure to follow the instructions. Incorrect installation







of the stand may result in the TV falling over.





1 Confirm that there are screws with the stand unit.







For 60 inch models







(Eight long screws and four short screws)





2Attach the supporting post for the stand unit onto the base using the long screws with a screwdriver as shown.

NOTE

To detach the stand unit, perform the steps in reverse order.

A screwdriver is not supplied with this product.

Supporting post

3Insert of the the

Front

into the openings on the bottom the stand so it will not drop from base area).

4
