Sharp LC-32D62U Useful adjustment settings, Language setting Reset, Image position

Page 34

Useful adjustment settings

Language setting

Reset

You can also select a language from the Setup menu. Select from among 3 languages: English, French and Spanish.

1

Press MENU to display the MENU screen, and

then press c/d to select “Setup”.



2

Press a/b to select “Language”, and then

press ENTER.



3

Press a/b to select the desired language

listed on the screen, and then press ENTER.



4

Press MENU to exit.



Image position

For adjusting a picture's horizontal and vertical position.

1

Press MENU to display the MENU screen, and

then press c/d to select “Setup”.



2

Press a/b to select “Position”, and then

press ENTER.



3

Press a/b to select “H-Pos.” or “V-Pos.”.









Example













H-Pos.

[

0]

a10

b10



V-Pos.

[

0]

a20

b20



Reset







Selected item







Description

H-Pos.

Centers the image by moving it to the left



or right.





V-Pos.

Centers the image by moving it up or



down.





4

Press c/d to adjust the item to the desired

position.



5

Press MENU to exit.



NOTE

For resetting adjustments to the factory preset values, press a/b to select “Reset”, and then press ENTER.

Adjustments are stored separately according to input source.

If complex adjustments are made and the settings cannot be restored to normal, you can reset the settings to the factory preset values.

1

Press MENU to display the MENU screen, and

then press c/d to select “Setup”.



2

Press a/b to select “Reset”, and then press

ENTER.





If you already set the Secret No., input the 4-digit





secret number here. See page 40 for setting a





secret number.



“Return to the factory preset values” displays on





the screen.

3

Press c/d to select “Yes”, and then press



ENTER.



“Now, TV will restart automatically. OK?” displays





on the screen.

4

Press c/d to select “Yes”, and then press

ENTER.





• “Now initializing...” displays on the screen and



blinks.



• After the reset has completed, the power shuts



off and then comes back on. The screen will have



returned to its original settings.

Now initializing...

NOTE

The Channel Setup settings will not be changed.

The Language settings will not be changed.

The Secret number settings will not be changed.

32
