Korg owner manual D3200 Shortcut Keys

Page 9

D3200 EasyStart

D3200 SHORTCUT KEYS

The D3200’s Shortcut keys provide instant access to the most commonly used functions in a recording and mixing session, such as meter view, channel input track assign, track editing, undo / redo, mixer automation and other repeatedly-used functions. To use a “Shortcut”, press and hold a specific key, then select or scroll through options with another key.

Here are a few Shortcut keys to check out…

Meter source options: Press and hold the METER key, and then scroll through the options available with the L/ R cursor keys.

Display Meter/Track: Change the track/fader view of the display. Press and hold the METER key then use the UP /

DOWN cursor keys.

Track editing options: Press and hold the TRACK key, and then 1) scroll through options with the +/- increment keys, or 2) press the channel keys above faders 1-15.

Automation options: Press and hold the MIXER key, and then press the SCENE key.

CH Input page: Press and hold the MIXER key, and then press the REC/PLAY key (above channel 14).

DrmsMixer page: Press and hold the MIXER key, and then press the CH VIEW key to instantly access your drum mixer.

Master EQ:Press and hold the MIXER key, and then press the Master EQ key.

Important D3200 Owner’s Manual References

MIDI Sync / MIDI Machine Control (MMC)

94

/ 124

Using MIDI to control Scenes / MIDI

94

/ 124

Working with WAV files and the Import/Export function

86-88

/ 136

Initializing/formatting and checking the internal hard drive

90

/ 121

Backing up and restoring data via CD-R or USB

82 / 92

Updating system software



96

Troubleshooting



164

Shortcut Keys



178

For more information, see the D3200 Owner’s Manual, and visit www.korg.com for more support, tips and tricks!

9

Image 9
Contents EasyStart EasyStart ContentsKnob Matrix Few words on ClickPoint…D3200’s Transport controls are shown as follows Meter keyCH View Key Track & Scrub keys Scene Automation The Scene keyRecording Automation on a track Effect & EQ Keys Mixer KeySession Drums Key Create a new song Assign an inputAssign effects and EQ to the input Mixdown and master your song Build a drum track with Session DrumsCreate an audio CD of your song Backup your data to computer using USBD3200 Shortcut Keys
