Before Using the Product

Copyright

The contents of this manual are subject to change without notice to improve quality.

© 2012 Samsung Electronics

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

zAn administration fee may be charged if either

†(a) an engineer is called out at your request and there is no defect in the product (i.e. where you have failed to read this user manual).

†(b) you bring the unit to a repair centre and there is no defect in the product (i.e. where you have failed to read this user manual).

zThe amount of such administration charge will be advised to you before any work or home visit is carried out.

Icons used in this manual

The following images are for reference only. Real-life situations may differ from what is shown in the images.

Symbols for safety precautions

Warning

A serious or fatal injury may result if instructions are not followed.



Caution

Personal injury or damage to properties may result if instructions are

not followed.



Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
