Samsung SVR-940/450 user manual System Setup

Page 41

Chapter 5. Configuration

Main Menu

Submenu

Default









SYSTEM ID

0



BAUD RATE

9600

RS-232

DATA BIT

8



PARITY BIT

NONE



STOP BIT

1









SYSTEM ID

1



BAUD RATE

9600

RS-422/485

DATA BIT

8



PARITY BIT

NONE



STOP BIT

1









E-MAIL





MAIL ADDRESS



E-MAIL

MAIL SERVER IP

OFF

ID







PW





RETURN MAIL ADDRESS









• SYSTEM SETUP

Main Menu

Submenu

Default









LANGUAGE

ENGLISH



KEY BUZZER

ON



DEFAULT

>>

SYSTEM

REMOTE SETUP

ON



REMOTE CONTROLLER ID

0



DESCRIPTION

DISPLAY



TEST MODE

>>







HDD

HDD FORMAT

APPLY

HDD DESCRIPTION

DISPLAY











USER AUTHENTICATION

>>

PASSWORD

USER PASSWORD

>>



EVENT BEEP

OFF









CLOCK

>>

CLOCK SETUP

DATE MODE

YYYY/MM/DD



MONTH TYPE

INITIAL









CHANNEL

CH1

PTZ

PTZ CAMERA ID

0



MODEL

NONE







Digital Video Recorder 41 User’s Manual
