Archos AV 500 series user manual Disconnecting the AV 500 from your Computer

Page 35

69

Windows® XP

Please verify** that you have Windows® XP and it is updated it to at least, Service Pack 1. You must also have Windows Media® Player 10 (WMP10) installed on your computer. This way, you can take advantage of connecting it as a ‘Windows Device’. Connect it to your PC as enumerated above and you can then see the AV 500 in Windows® Explorer and WMP10. Without Windows® XP Service Pack 1 (a free update) or Windows Media Player® 10, you cannot use it as a Windows® recognized ‘Device’ and will have to follow the instructions for Windows® ME & 2000 below.

**Right-click on ‘My Computer’ select ‘Properties’, and then look in the tab labeled ‘General’. It should say “Service Pack 1” or higher.

Windows® ME and 2000

Attention: Before connecting the AV 500 to your computer with the

USB cable, go to the setup action icon and then to System and USB

Port and change it to ‘Hard Drive’.

When connected to your computer, the AV 500 will be recognized as an external Hard Drive and display automatically within a few seconds of being connected. You will see a new drive letter, such as E: in My Computer called AV 500. You can now use the hard drive called AV 500 like any other external hard drive. Simply access it using Windows® Explorer to drag and drop files to and from the AV 500’s hard drive.

Macintosh™ OS X

If you have OS X, you must update to version 10.2.4 or newer. You must also change the AV 500’s USB Port setting to ‘Hard Drive’. From the main menu, go to the Settings action icon and then to System and USB Port and change it to ‘Hard Drive’.

You will now simply plug the AV 500 into your Macintosh® as enumerated above, and within a few seconds, the AV 500 will be recognized as a mass storage device (Hard Drive) and mount on the desktop. You can now use the hard drive called AV 500 like any other external hard drive.

69

70

17.3 Disconnecting the AV 500 from your Computer

Windows Device Mode

If the AV 500 is connected to your computer as a Windows Device, verify that no data is being transferred between your AV 500 and your computer (the HDD light on your AV 500 is not flickering). You can now safely unplug the USB cable from your AV 500 and/or computer.

Hard Drive Mode

If the AV 500 is connected to your computer as a hard drive, DO NOT SIMPLY PULL OUT THE USB

CABLE AT ANY TIME!

WARNING: You must properly remove (unmount) your AV 500 from the computer before disconnecting the USB cable to avoid loss of data or freezing the computer and/or the AV 500.

Hard Drive Mode & Windows®

To safely disconnect the AV 500 hard drive, click on the system tray remove icon (green arrow as shown below) and follow the instructions. Wait until you get a message saying that you can safely unplug the device before disconnecting the USB cable.

1. The safe remove icon is in the system tray next to the clock.

Windows® XP

Windows® 2000 & Windows® ME

2. Click on the icon to eject (unmount) the AV 500 from the computer and select the ‘Safely remove’ message.

3. There will be a message indicating that it is now safe to disconnect the AV 500. You can now safely unplug the USB cable from your AV 500 and/or computer.

70
