Archos AV 500 series user manual Clock Settings, Display Settings

Page 38

75

Repeat & Shuffle options



Normal

Plays your songs one after the other and then stops after the last song.

Repeat

Continuously plays through the current set of songs (Artist, Album, folder, or Playlist).

Shuffle

Randomly play through the current set of songs (Artist, Album, folder, or Playlist).

Intro duration

From 10 to 90 seconds. This is the time for which each song will be played when selecting Scan for Playmode



settings.

19.3 Clock Settings

The AV 500 has an internal real time clock. The time of day is shown on the top right of the screen in either 24 hour or 12 hour display mode. To set it, select the Settings action icon then select Clock.

Choose parameter

Choose value for



highlighted parameter

When finished setting the parameters, move down to the clock time and date are now set. Click on the STOP/ESC x

Set button, then click on the ENTER o button. The button to go back to the main settings menu.

75

76

19.4 Display Settings

These settings regulate the interface language and the presentation of the screen.

Setting

Description

Language

The AV 500 can be set to English (default), French, German, Spanish, or Russian.

Action icon help

Displays the explanation or name of the action icons when moving up and down through the menu. If set to On, the



first click on the SELECT action button will show the names of the icons. The second click will select the icon.

TV Standard

NTSC (USA), PAL (Europe). In order to view images or videos on an external television, select one option to send



the video signal compatible with your country’s television system. Countries other than European or American will



use one of these two systems.

TV format

4:3 or 16:9 – the ratio at which images are displayed on your television set.

Video Output

Internal LCD or External TV. To display via the built-in LCD screen or to view the display via an external television.



Holding the LCD/TV button for two seconds will also alternate between these two options. Be sure your television is



selecting the correct external input.

LCD Brightness

0, 1, 2. The 3 brightness levels for the built-in LCD screen. Setting to a lower value will give you a longer battery



autonomy.

When accessing the Display settings while playing a video you have an additional display option:

Video OSD

Time for which the video On Screen Display information will be shown when the video starts playing.

76
