Archos AV 500 series user manual Connecting Devices to the USB Host Port

Page 36

71

Hard Drive Mode & Macintosh®

Drag the AV 500 hard drive icon towards the trash can, the trash can will become a big arrow as shown in the screen shot to the left. Drop the hard drive icon onto the arrow. The hard drive icon will disappear from the desktop. You can now safely unplug the USB cable from your AV 500 and/or computer.

71

72

18 Connecting Devices to the USB Host Port

Thanks to the USB Host port, you can connect USB Mass Storage Class (MSC) devices such as many digital cameras and external hard drives in order to transfer pictures or data to/from your AV 500. Check your manufacturer’s information to find out whether your device is an MSC device. Non Mass Storage Class devices such as printers, Ethernet adapters, mice, keyboards, etc. are not supported. To connect an MSC device, use the included short USB host adapter.

If your camera follows the Mass Storage Class (MSC) standard for USB connection, then your camera will show up in the file browser as the folder /External USB. If you look in this folder you will see your photos or files. See the chapter on the File Browser for instructions on how to copy files.

72

Page 35 Page 37
Image 36
Page 35 Page 37
Contents Archos Mobile Video Recorder AV 500 Series Table of contents Music Using iTunes with your AV Photo Viewing Photos Browser Using the BrowserConnecting/Disconnecting* the AV 500 to/from your PC Connecting Devices to the USB Host PortReplacing the battery Technical Support Troubleshooting1INTRO Buttons and Connections Technical Specifications Legal 100 Index 104Page 2INTRO First Time Usage Hardware Reset 3VIDEO Playing Video FilesVideo Playback Action Icons Resume Function4VIDEO Playing Video Files from the Internet 5VIDEO Recording Video Files Video recording connectionsRecording a video file Setting the Recording Parameters Where is the Recording Saved?Manually Setting the Scheduler Copy Protection6VIDEO Automated Yahoo! TV Recording Scheduler 7VIDEO Setting the Infrared Emitter Code Part 1 Choose your Device and Brand Part 2 Finding the Right Emitter Codes8VIDEO Editing Video Files Important NoteHow to create an MPEG-4 video file 9VIDEO Creating MPEG-4 Video Files with your ComputerPC Tools Installing the PC Software Using MPEG-4 TranslatorMPEG-4 codec Compression/Decompression Virtual Dub MPEG-4 TranslatorChange Settings Select Source & Destination FilesTarget & Priority StartMusic Playing Music Files Button ControlPlay Screen Icons Display during music playbackPlay Mode Browsing through your Music LibrarySetting a Bookmark Playing Through your Stereo SystemPlaysForSure audio content Music Putting Music onto your AVSynchronizing Music from Windows Media Player WMP to the AV Supports protected Internet video downloadsMusic Playlists Saving a Playlist Adding songs to a Playlist while listening to MusicMusic Recording Music Cable Connections for Audio RecordingRecording Procedure MicrophoneAudio Editing Incremental RecordingMusic Using iTunes with your AV Photo Viewing PhotosViewing Photos Viewing a slideshow Transferring photos to your AVMagnifying Photos Methods to copy photos to your AVBrowser Using the Browser Navigating the Directory Structure File and Folder OperationsInfo CreateDrive contents Copying and Moving Files and FoldersPhoto View Connecting/Disconnecting* the AV 500 to/from your PC Using the Virtual KeyboardConnecting the AV USB Connection Type ‘Hard Drive’ or ‘Windows Device’Disconnecting the AV 500 from your Computer Connecting Devices to the USB Host Port Sound Settings Play Mode SettingsClock Settings Display SettingsAppearance settings Power SettingsSystem Settings Updating the AV 500 Firmware Operating System OS TV controlTV docking pod Description ‘Hard Drive’ or ‘Windows Device’?Connecting the TV docking pod to your Television System Remote Control DescriptionConnection 1 Powering the TV docking pod Connect & Test MethodConnection 2 Breaking your regular TV Connection Connection 4 Connect the AV 500 to the TV docking podConnecting it to the TV docking pod Connection 5 the S-VideoConnection 6 the Infrared Emitter Which device to control?Replacing the battery Thin versionStandard version Technical Support Telephone SupportTroubleshooting USB Connection issuesSolutions Charging and Power issues File issues, corrupted data, formatting, and partitioning25.3 AV 500 locks up freezes operation or Stops Technical Specifications Physical Dimensions Temperature RangeWarranty and Limited Liability LegalFCC Compliance Statement Electrostatic Discharge Avoiding Hearing DamageCopyright Notice LCD Pixel Policy Environmental Considerations105 107 109

AV 500 series specifications

The Archos AV 500 series, launched in the mid-2000s, marked a significant step in portable multimedia players, setting the stage for how we consume media on the go. This innovative series stood out for its combination of storage capacity, multimedia capabilities, and user-friendly interface, making it a favorite among tech enthusiasts and casual users alike.

One of the hallmark features of the Archos AV 500 series was its sizeable hard drive, available in various capacities ranging from 20GB to 100GB. This ample storage allowed users to carry thousands of songs, hundreds of videos, and a variety of pictures. The player supported multiple formats, including MP3 and WMA for audio, as well as AVI and MPEG for video playback. The versatility in supported formats contributed significantly to its user appeal, enabling seamless playback of various media types.

The Archos AV 500 series was equipped with a 4-inch color LCD screen, delivering a sharp and vibrant viewing experience for videos and images. The device also supported a resolution of 480 x 272 pixels, ensuring that video playback was both smooth and visually pleasing. This emphasis on screen quality made it a popular choice for users looking to enjoy their media content on the move.

In terms of connectivity, the AV 500 series featured USB 2.0 for rapid file transfers, allowing users to quickly upload and download their favorite media. It also included an SD card slot, enabling users to expand storage capacity easily, a great advantage for those who needed more space for their content.

The Archos AV 500 series boasted an intuitive interface, featuring an easy-to-navigate menu that catered to users of all ages. The touchscreen operation facilitated quick access to media libraries, settings, and playback options, ensuring that the user experience was both efficient and enjoyable.

Moreover, the series included features such as video recording capabilities, allowing users to capture live events or personal moments directly onto the device. This recording function combined with the playback features created an all-in-one multimedia hub.

In conclusion, the Archos AV 500 series was a groundbreaking device in the portable media player market, offering an impressive combination of storage, versatility, and user-friendly technology. Its innovations paved the way for future developments in multimedia devices, leaving a lasting impact on how we engage with digital content.
